Dental Diode Laser System Photo-Activated Heal laser Pen Soft Tissue Perio Endo

DESCRIPTION：

1.Photo-Activated Disinfectiontechnology is based on two components to selectively tag and destroy cariogenic bacteria and periodontal pathogens: a solution of dilute, pharmaceutical grade tolonium chloride (a vital stain) and light of a specific wavelength (650 nm) to activate the solution.Photo-Activated Disinfection (PAD) Light-F3WW provide the light of a specific wavelength (650 nm) to activate the solution.
Introduced into dental hard or soft tissue, thesolutionof dilute, pharmaceutical grade tolonium chloride (a vital stain)selectively targets and tags all bacteria. When the solution isactivated by the Photo-Activated Disinfection(PAD) Light-F3WW,it releases singlet oxygen whichruptures the cell walls of bacteria, killing them in seconds.

Indications for Use：

1.Photo-Activated Disinfection(PAD) Light-F3WW is equally effective to activate the solution on the bacteriafound in root canals, periodontal pockets, periimplantitis,carious teeth,Infection control and pain relief.
2.Kills all bacteria including: Streptococcus mutans/ Total streptococcus/Streptococcus sobrinus/ Streptococcus intermedius/ Actinomyces/ Lactobacillus/ veilonella/ Prevotella intermedia/ Peptostreptococcus micros/ Fusobacterium nucleatum/ Porphyromonas gingivalis/Staphaloccoccus aureus/ E.faecalis

Note:
1.The PAD Light and accessories are provided non-sterile. Cleaning and sterilization of accessories and components that come in contact with open tissue is required prior to use on patients.
2.Do not stare into the visible light. Laser light is emitted from this device. Avoid extreme exposure. Do not point the device at anyone’s eyes.
3.The device will need to be fully charged prior to the first use. Plug the AC recharging power cord into the unit and then into the wall socket. Charge for at least 12 hours before the first use.
4.Recharge the device at least once every 3 weeks whether you have used the device or not.Put battery into the cylinder of the the charge station ( Contact PCB faces down), the green light turns on when it’s charging, the light will turn off when the battery get full charge. It’s about 2 hour to get full charge.
5.Because the device contains a laser, do not shine it directly into your eyes or look directly at the laser light. Do not point the PAD Light device at your or another person’s eyes.

Technical Specification：
Wavelength：650nm ± 5nm
Power：200mw
Diameter：18.5mm
Weight:1100g
Length without a light rod：102mm
Diameter of the out put of the light rod：6mm
