Sensor type
|
Analog signal cable displacement sensor
|
|
Measuring Range
|
0-5000mm
|
|
Linear Accuracy
|
0.25% FS
|
|
Repeatability Accuracy
|
0.01%
|
|
Output
|
0-10V
|
|
Wire retraction force
|
10N
|
|
Maximum reciprocating speed
|
1000mm/s
|
|
Protection level outside the pull box
|
IP54
|
|
Life
|
More than 2 million reciprocating cycles
|
|
Operation temperature
|
-30℃~+90℃
|
|
Working voltage
|
12V
|
|
Cable Length
|
Optional；Standard configuration 2m
|
|
Wire rope diameter
|
0.7mm Imported coated steel wire rope
|
|
Housing Material
|
Aluminium alloy,wear and corrosion prevention
|
Can be equipped with a digital display meter to display distance line speed.
The product can be applied to crane hoist testing, automatic storage testing, testing machine testing, various guide rail systems, hydraulic cylinder systems, telescopic systems, pressure machinery, various production lines, textile machinery, packaging machinery, printing machinery, heavy industry machinery and other positions. Crane hoist testing, automatic storage testing, testing machine testing, various guide rail systems, hydraulic cylinder systems, telescopic systems, pressure machinery, various production lines, textile machinery, etc, Position measurement control and automatic control of packaging machinery, printing machinery, heavy industry machinery, etc.
