• Parallel light source output, more concentrated light source energy output, better curing effect.
• Wireless charging technology that complies with the QI WPVC1.1 wireless charging protocol standard.
• High electro-optical conversion efficiency, fully charged can be used more than 500 times (full power P2 mode 10s timer count, battery full charge to battery low power alarm number).
• Ergonomic design to increase the grip texture and treatment comfort.
• Aluminum alloy body, anti-fall, anti-fall.
• Light source design with 360° rotation, suitable for multi-angle curing operation.
• Removable and replaceable light source design, 400nm ~ 420nm light source with the corresponding dental reagents, can be used to detect dental caries.
• By equipping with a special whitening bar, the blue light source is provided to the teeth whitening agent to achieve the effect of auxiliary teeth whitening.
• The charging base has an optometry function that can be used to verify that the radiation output of the curing machine reaches the effective radiation value.
• The point curing lens can be installed at the light source to achieve the ideal curing effect when bonding the all-porcelain veneer with the crown and the root canal fiber post.
• The lithium battery can be replaced, and the host can automatically shut down.
The battery is protected against overvoltage, overcurrent, and short-circuit.
| Nominal Voltage | 3.7V |
| Capacity | 2200mah |
| Battery Model | ICR 18650 |
| Input | 100-240V to 50/60Hz |
| Fuse | T1A 250V |
| Input Power | 5VA |
| Output | 5V 1A |
| LED Light | 5W |
| Radiation | ≧850mw/Cm2 |
| Radiation | 400nm ~ 480nm |
| Light Source Optical Effective Area | 75mm2 |
| Ambient Temperature | 5°C to 40°C |
| Relative Humidity | <80% |
| Atmospheric Pressure | 75kpa ~ 106kpa |
1 X Light Curing
1 X Power Adapter + Data Cable
1 X Charging Base
1 X 440~480nm Light Source Head
100 X Disposable Isolation Kit
