Dental Intraoral Camera WIFI Digital lmaging Intra Oral HD 300W Pixel 8LED Light



Product introduction:

This series of products is a portable wireless visual dental camera with supplement LED light around the lens, can image oral through wireless signal. Real-time transmission to mobile phone, tablet PC, smart TV, smart mirror, computer and other smart device, and provide video, photograph and other functions to help you check oral.



APP Download:

【Method 1】Open the mobile app store, Search “EndoCamera”, and click Download and Install. (Huawei Application Market/ Xiaomi App Store /OPPO App Store VVO App Store /iPhone App Store/, Tencent App treasure /360 mobile phone assistant can be searched and Download.)

【Method 2】Scan the QR code, select "EndoCamera.apk" to download and install the APP.

Note: When installing App “Endocamera”, please allow all the authority request it need.



Application:

1. Keep press the switch/Photo button for 2 seconds to start the machine.

2.When using by mobile phone, manually connect to a WiFi hotspot in WLAN 1. Settings. Open the downloaded APP, enter the interface in Figure 1, and click "EC-3" to connet. Enter the interface shown in Figure 2, manually connect the WIFI "EC3_XXXXX" and return Then enter the device interface as shown in Figure 3. Click the "Start" button to start showing image. Click the "Close" button to power off the device and exit the APP.

3. For computer using, it needs to manually connect to the WiFi in WLAN Settings. Type in the website on web browser ” vvdental.com.cn”, Click the "Data Download" column to download EndoCamera_install.exe to install, After the installation, open the PC client software,You need to disconnect from the original network. manually connect the hot spot "EC-3-XXXX", and click the" Start playing " button in the page to showing image.



Note: Please fully charge the battery before starting the product for the first time. Please use 5V USB charger externally. (Such as 5V1A mobile phone charger, can’t use the power supply exceeding the rated voltage and current)



Specification:

Model Name: EC-3

Size: 210*25*20mm

Image pixel: 300W

Frame Rate: 20fps

Fno.: 2.4

FOV : 90°

Focal length:12~40 mm

LED Light: 8PCS

Operate Voltage: 3.7V

Operate Current: 200mA

Head Size: 6*6*3.9mm

Waterproof Level/; Ip56

Battery Capacity: About 500mAh

Operate Ambient Temperature: -10°~ 50°

Operate Ambient Humidity: 45% ~ 80%

Operate Time: About 150min

Wireless Transmission Distance: 20m

Note: Due to the continuous improvement of products, such as the technical parameters in this manual are modified without prior notice.

If you are unable to install the software, please contact me and I will assist you in resolving the issue!!
