KAC For 1999-2007 GMC Sierra 1500 2000-2006 Yukon Headlights Assembly Smoke Lens



Product Description:



Designed for:

Reference Number: GM2502188, 15289275, 15850351, 16526135,

                             GM2503188,15289276,15850352,16526136





Bulb Type:

  • 9005 High Beam (NOT included)
  • 9006 Low Beam (NOT included)
  • 3157 Turn Signal Light (NOT included)



FITMENT:



  • For 1999-2006 For GMC Sierra 1500/2500
  • For 2001-2006 For GMC Sierra 1500HD/2500HD/3500
  • For 2007 For GMC Sierra 1500 Classic/ 1500HD Classic/2500HD Classic/3500 Classic
  • For 2000-2006 For GMC Yukon
  • For 2000-2006 For GMC Yukon XL 1500/ 2500

(* Don't fit for C3 or Denali )



PACKAGE INCLUDES:



2Pcs Headlights Housing (1x Driver's side & 1x passenger's side)







Note:



Due to lighting effect, monitor's brightness etc, there could be some slight differences in the color between
the photo and the actual item





Installation:



1).How to install:

1.Undo the screws, clips, or retainer springs that hold the headlight in place.

2.Disconnect the wiring from the assembly.

3.Detach the headlight from the vehicle to replace it with a new one.

4.Fit in the new headlight assembly.

5.Fix the new headlight into place and make sure that the screws, clips, or retainer springs used are sealed.

6.Reconnect the wiring that was unplugged from the assembly.

7.Put back the grille and other components that you removed. Seal them back into place.

8.Test the new assembly.



2).How to adjust:



Before you begin to adjust the light, make sure check the alignment of your lights first. Park the vehicle about 10 to 25 feet from the wall with the lights aimed at the wall. The centerlines of the headlights should not be any higher than 3.5 feet above the ground.



1. Find the adjustment screws.Firstly, locate the adjustment screws on your vehicle.

2. Adjust the headlights individually. The headlights should be adjusted one at a time. Put a rag or towel over a chair in front of the light you want to block. Covering the light assembly directly can damage the plastic lens.

3. Adjust the vertical field. The screw on the top of the light housing should be turned clockwise to raise the lights and counterclockwise will lower the light. The headlight should be adjusted until the top of the most intense part of the light beam shines directly on or just below the center of the tape line on the wall.

4.Test your results.







Product Description:



Designed for:

Reference Number: GM2502188, 15289275, 15850351, 16526135,

                             GM2503188,15289276,15850352,16526136





Bulb Type: 9005 High Beam (NOT included)

                    9006 Low Beam (NOT included)

                      3157 Turn Signal Light (NOT included)



FITMENT:



  • For 1999-2006 For GMC Sierra 1500/2500
  • For 2001-2006 For GMC Sierra 1500HD/2500HD/3500
  • For 2007 For GMC Sierra 1500 Classic/ 1500HD Classic/2500HD Classic/3500 Classic
  • For 2000-2006 For GMC Yukon
  • For 2000-2006 For GMC Yukon XL 1500/ 2500

(* Don't fit for C3 or Denali )



PACKAGE INCLUDES:



2Pcs Headlights Housing (1x Driver's side & 1x passenger's side)







Note:



Due to lighting effect, monitor's brightness etc, there could be some slight differences in the color between
the photo and the actual item





Installation:



1).How to install:

1.Undo the screws, clips, or retainer springs that hold the headlight in place.

2.Disconnect the wiring from the assembly.

3.Detach the headlight from the vehicle to replace it with a new one.

4.Fit in the new headlight assembly.

5.Fix the new headlight into place and make sure that the screws, clips, or retainer springs used are sealed.

6.Reconnect the wiring that was unplugged from the assembly.

7.Put back the grille and other components that you removed. Seal them back into place.

8.Test the new assembly.



2).How to adjust:



Before you begin to adjust the light, make sure check the alignment of your lights first. Park the vehicle about 10 to 25 feet from the wall with the lights aimed at the wall. The centerlines of the headlights should not be any higher than 3.5 feet above the ground.



1. Find the adjustment screws.Firstly, locate the adjustment screws on your vehicle.

2. Adjust the headlights individually. The headlights should be adjusted one at a time. Put a rag or towel over a chair in front of the light you want to block. Covering the light assembly directly can damage the plastic lens.

3. Adjust the vertical field. The screw on the top of the light housing should be turned clockwise to raise the lights and counterclockwise will lower the light. The headlight should be adjusted until the top of the most intense part of the light beam shines directly on or just below the center of the tape line on the wall.

4.Test your results.







Item Specifics
Brand KAC
Manufacturer Part Number GM2520174_1999 2000 2001 2002 2003 2004 2005 2006
OE/OEM Part Number GM2502188, GM2503188
UPC 997750704718
Interchange Part Number GM2502188, GM2503188, GM2520174, GM2521174
Type Headlight Assembly
Features DOT-Certified
Manufacturer Warranty 5 Years
Lens Color Clear
Placement on Vehicle Left, Right, Front
Housing Color As the Pictures
Headlight Style Factory
Bulbs(Headlight) Low: 9006 Not Included / High: 9005 Not Included
Bulbs Not Included
Package Include Driver Left Side & Passenger Right Side
Certifications DOT, SAE
MPN YIA704718
