Compatibility:

2019 For lexus ES350
2018-2019 For toyota Camry
2019-2020 For toyota RAV4





Features:

  • -OE design to ensure exact fit, form and function for an easy drop-in installation;
  • -Built with high density multi-lowered fins for maximum cooling efficiency;
  • -ISO 9001 certified manufacturing plants;
  • -Direct Replacement;
  • -Improve Cooling Efficiency;
  • -100% Leak Tested;
  • -Plastic tanks with aluminum core;
  • -Built to strict quality control standards;





How to clean radiator:

1. Start the vehicle, to rise to normal temperature. Slowly open the tank cover, the fluid shake from the tank after filling the mouth, the cleaner can be mixed with any brand of coolant. Idle running not less than 15 minutes, not cleaning vehicles not less than 30 minutes for two years. And then discharge coolant, flush water tank, until out of clear water, suitable for any water cycle system.

2. After cleaning, after waiting for pipeline rehabilitation add fluid to water tank, and inject new coolant and water purification.





How to replace the radiator:

1. Disconnect the battery.

2. Drain the radiator fluid into a suitable container.

3. Remove the old radiator:

 -Take off any plastic covers around the radiator.

 -Disconnect the electrical connector to the fan, and unbolt and remove the fan assembly.

 -Disconnect the radiator hoses from the radiator.

 -Disconnect the transmission cooling lines from the bottom of the radiator.

 -Remove any clamps, brackets, or screws holding the radiator inside its frame.

 -Lift the radiator up and out of the car.

4. Install the new radiator:

 -Slide the new radiator into place.

 -Connect any clamps or brackets that hold the radiator in place.

 -Connect the transmission cooling lines carefully.

 -Connect the engine cooling hoses to the radiator.

 -Replace the fan and fan shroud.

 -Reconnect the fan electrical connection.

 -Replace the plastic covers.

5. Fill the radiator with fluid.

6. Check your work to make sure that there are no leaks.

(Tools need to be prepared: Screwdrivers, Wrenches, Drain pan)

Note: Do please keep children and pets away when replacing the radiator)





Package:

1pc of brand new radiator

Compatibility:



2019 For lexus ES350
2018-2019 For toyota Camry
2019-2020 For toyota RAV4



Features:

-OE design to ensure exact fit, form and function for an easy drop-in installation;

-Built with high density multi-lowered fins for maximum cooling efficiency;

-ISO 9001 certified manufacturing plants;

-Direct Replacement;

-Improve Cooling Efficiency;

-100% Leak Tested;

-Plastic tanks with aluminum core;

-Built to strict quality control standards;



How to clean radiator:

1. Start the vehicle, to rise to normal temperature. Slowly open the tank cover, the fluid shake from the tank after filling the mouth, the cleaner can be mixed with any brand of coolant. Idle running not less than 15 minutes, not cleaning vehicles not less than 30 minutes for two years. And then discharge coolant, flush water tank, until out of clear water, suitable for any water cycle system.

2. After cleaning, after waiting for pipeline rehabilitation add fluid to water tank, and inject new coolant and water purification.



How to replace the radiator:

1. Disconnect the battery.

2. Drain the radiator fluid into a suitable container.

3. Remove the old radiator:

 -Take off any plastic covers around the radiator.

 -Disconnect the electrical connector to the fan, and unbolt and remove the fan assembly.

 -Disconnect the radiator hoses from the radiator.

 -Disconnect the transmission cooling lines from the bottom of the radiator.

 -Remove any clamps, brackets, or screws holding the radiator inside its frame.

 -Lift the radiator up and out of the car.

4. Install the new radiator:

 -Slide the new radiator into place.

 -Connect any clamps or brackets that hold the radiator in place.

 -Connect the transmission cooling lines carefully.

 -Connect the engine cooling hoses to the radiator.

 -Replace the fan and fan shroud.

 -Reconnect the fan electrical connection.

 -Replace the plastic covers.

5. Fill the radiator with fluid.

6. Check your work to make sure that there are no leaks.

(Tools need to be prepared: Screwdrivers, Wrenches, Drain pan)

Note: Do please keep children and pets away when replacing the radiator)



Note:

1. Project operation, the vehicle normal temperature 60 to 80 degrees.

2. Add detergent if the tank is too full can take some antifreeze.



Package:

1pc of brand new radiator

Item Specifics
替换1库存 #N/A
替换2库存 #N/A
毛利率 0.00401918188044
匹配库存 3
价格差 -3.28
Brand KAC
Type Radiator
Items Included N/A
Material Aluminum, Plastic
Manufacturer Part Number RK1858
OE/OEM Part Number 13670
Manufacturer Warranty 5 Years
Outlet Diameter 1.5 in. / 38.1 mm
Interchange Part Number For CU13670 13670 Aluminun Core, 2018 2019 2020 Lexus Toyota Camry ES350 RAV4 AWD FWD, 4-Wheel ABS Front Sedan Sport Utility 4 Cyl 6 Cyl L4 V6 2.5L, 3.5L Adventure Base F Sport Hybrid LE Hybrid Limited Hybrid XLE, Hybrid XSE L LE Limited Luxury Premium SE Signature TRD Off-Road, Trail Ultra Luxury XLE XLE Navi XLE Premium XSE Radiator
UPC Does not apply
Color Silver Core, Black Tank
Core Height 27.44 In. / 697 mm
Core Material Aluminum
Core Thickness 0.63 In. / 16 mm
Core Width 17.63 In. / 697 mm
Fitment Type direct replacement
Hardware Included No
Has Engine Oil Cooler No
Inlet Diameter 1.5 in. / 38.1 mm
Inlet Header 18.38 x 1.88 in. / 466.7 x 47.6 mm
Inlet Location Bottom Left
Mounting Hardware Included No
Outlet Header 18.38 x 1.88 in. / 466.7 x 47.6 mm
Outlet Location Bottom Right
Radiator Cap No
Row Count 1 Row
Sensor 2
Style Crossflow
Tank Material Plastic
Transmission Oil Cooler No
Transmission Type Automatic Transmission
Placement on Vehicle Engine Compartment
