DeatschWerks X2 Pump Module for 2012-2016 Scion FR-S, 2012-2020 Subaru BRZ
DEATSCHWERKS X2 Pump Module
for 2012-16 Scion FR-S, 2012-20 Subaru BRZ, 2017-20 Toyota 86
X2 Series Fuel Pump Module for 2012-16 Scion FR-S, 2012-20 Subaru BRZ, 2017-20 Toyota 86
Note: This fuel pump module requires a regulated return style fuel system.
The new DeatschWerks X2-Series Toyota, Subaru, Scion Module is now available for the 2012-2021 GT86, BRZ and FR-S, which includes accommodation for 2 pumps, integration of a return fuel line, and retention of ALL the functionality of OE module. The DW X2-Series module consists of a top-hat, center section, and OE lower bucket. These components work together to deliver the flow you need and the OE functionality you want.
? OEM Tank Fitment
? Keeps OEM Level Sensor, Capacity and Surge Features
? Fits 2012-2021 Toyota, Subaru, Scion GT86, BRZ and FR-S
? 260% Flow Over OEM Module
? Includes OEM Replacement Parts (Bucket, Level Sensor, etc)
This module is designed to fit the following applications:
2012-2016 Scion FR-S
2012-2020 Subaru BRZ
2017-2020 Toyota GT86
Included Parts:
? Billet Aluminum GT86 X2 Module
? 10" Pump Electrical Connectors (x2)
? Convoluted Tube 6" x 5/16"
? Convoluted Tube 12" x 5/16"
? Convoluted Tube 5" x 1/8"
? Convoluted Tube 4" x 5/16"
? 5/16" Barb to 3/8" EFI Quick Connect Fitting
? Fuel Sock Pump Pre-Filter (x2)
? 3/8" Pinch Hose Clamp (x2)
? 5/16" Pinch Hose Clamp (x4)
? 6mm Hose Clamp (x3)
? 12-10awg #10 Ring Terminals (x3)
? 14-16awg #10 Ring Terminals (x4)
? 18-22awg #10 Ring Terminals (x4)
? 6AN ORB to 5/16" Hose Barb Fitting
? 6AN ORB to Fuel Pump Adapter Fittings (x2)
? 4AN ORB to 5/16" Hose Barb Fitting (x2)
? 4AN ORB to 1/8" Hose Barb Fitting (x2)
? M5 Stainless Electrical Terminals (x3)
? M4 Stainless Electrical Terminals (x2)
? OEM Style Plastic Bucket Assembly
? OEM Style Fuel Level Sensor
? OEM Style Fuel Level Arm and Float (GT86 Specific)
? OEM Style Rubber One Way Valve
? Module Support Springs
? M5 Flange Head Allen Bolts (x3)
? 1/4"-20 Flange Head Allen Bolt
? 1/4"-20 Nyloc Nut
