Describe:
The tensioner is the key part of the winding machine. It generates adjustable tension during winding, so that the enameled wire is wound with appropriate tension, so that the wound coil is tight and compact, and the coil technical indicators are consistent.
feature:
Magnetic damping tensioner, also known as permanent magnet tension controller, is a device that transmits constant torque with a magnetic field as a medium. The damping disc is not in contact with the magnet, no sliding friction, long service life, and extremely stable tension control.
Rotating parts are precision machined from lightweight, strong materials with minimal moments of inertia.
The tension output rubber wheel adopts elastic soft rubber, which does not hurt the line.
The metal parts are rust-proof and have excellent corrosion resistance.
The installation structure is simple, the tension adjustment is convenient, the structure is compact, the size is compact, and the operati on is stable at each position
Tension adjustment method:
It is recommended to adjust the scale value to 3 or more. If the tension is too high at this time, it is better to use a small size damper.
If used below scale value 3, force pulsation may occur. Eliminate the pulsation as described in item 3 below.
Loosen the set screw, turn the scale to 10, slowly turn the scale to 0 while turning the spindle, then turn to the desired scale value. Tighten the locking screw.
If tension pulsation occurs during use, repeat the steps of adjustment method 3 above until a satisfactory tension is obtained.
The damper uses a magnet to generate a dielectric magnetic field, and the material is brittle. Therefore, do not disassemble it during use to avoid damage to the machine.
