Ceiling Snap Installation
Product Features:
1. Fresnel lens, high sensitivity, fast and stable response speed
2. Delay time and adjustable light sensitivity.
3. Preferred terminals, stable connection, easy and fast installation with ceiling mounting clips.
4.PC flame retardant material, effectively prevent fire hazards, high temperature resistance, long-lasting durability.
5. Wide range of use, compatible with incandescent lamps, energy-saving lamps, ceiling lamps, downlights, light strips, etc.
Product Parameters:
Product name: time-delayed infrared sensor probe
Working voltage: AC220V
Rated current: 4A
Load power: ≤ 40W, energy-saving lamps, LED lamps, fluorescent lamps, etc.
Mode setting: dark, dim, all day adjustable
Delay time: 3 seconds, 45 seconds, 4 minutes, adjustable
Sensing distance: 3-5 meters
Light sensitivity: 10LUX
Sensing principle: infrared human body sensing
Applicable places: corridor, hallway, bathroom, living room, etc.
Package list:
Sensor switch* 1
1. Fresnel lens, high sensitivity, fast and stable response speed
2. Delay time and adjustable light sensitivity.
3. Preferred terminals, stable connection, easy and fast installation with ceiling mounting clips.
4.PC flame retardant material, effectively prevent fire hazards, high temperature resistance, long-lasting durability.
5. Wide range of use, compatible with incandescent lamps, energy-saving lamps, ceiling lamps, downlights, light strips, etc.
Product Parameters:
Product name: time-delayed infrared sensor probe
Working voltage: AC220V
Rated current: 4A
Load power: ≤ 40W, energy-saving lamps, LED lamps, fluorescent lamps, etc.
Mode setting: dark, dim, all day adjustable
Delay time: 3 seconds, 45 seconds, 4 minutes, adjustable
Sensing distance: 3-5 meters
Light sensitivity: 10LUX
Sensing principle: infrared human body sensing
Applicable places: corridor, hallway, bathroom, living room, etc.
Package list:
Sensor switch* 1
Embedded Installation
Specification:
Type: Motion Sensor light Switch
Color: White
Output form: SCR
Working voltage: wide voltage AC 85-265 (V)
Induction principle: infrared sensor
Output power:≤40W
Mode Setting: Deep Dark/light Dark/All day
Sensing Distance: 4-6m
Delay off time: 3 seconds 45 seconds 4 minutes
Angle Coverage: 110°
Extreme Temperature Using: -10 celsius-+45 celsius
Standby power consumption: <0.1W
Scope of application: interior decoration ect.
Specifications: Opening 26mm
Package included：
1*Motion Sensor light Switch
Type: Motion Sensor light Switch
Color: White
Output form: SCR
Working voltage: wide voltage AC 85-265 (V)
Induction principle: infrared sensor
Output power:≤40W
Mode Setting: Deep Dark/light Dark/All day
Sensing Distance: 4-6m
Delay off time: 3 seconds 45 seconds 4 minutes
Angle Coverage: 110°
Extreme Temperature Using: -10 celsius-+45 celsius
Standby power consumption: <0.1W
Scope of application: interior decoration ect.
Specifications: Opening 26mm
Package included：
1*Motion Sensor light Switch
Ceiling Snap Installation
Product Features:
1. Fresnel lens, high sensitivity, fast and stable response speed
2. Delay time and adjustable light sensitivity.
3. Preferred terminals, stable connection, easy and fast installation with ceiling mounting clips.
4.PC flame retardant material, effectively prevent fire hazards, high temperature resistance, long-lasting durability.
5. Wide range of use, compatible with incandescent lamps, energy-saving lamps, ceiling lamps, downlights, light strips, etc.
Product Parameters:
Product name: time-delayed infrared sensor probe
Working voltage: AC220V
Rated current: 4A
Load power: ≤ 40W, energy-saving lamps, LED lamps, fluorescent lamps, etc.
Mode setting: dark, dim, all day adjustable
Delay time: 3 seconds, 45 seconds, 4 minutes, adjustable
Sensing distance: 3-5 meters
Light sensitivity: 10LUX
Sensing principle: infrared human body sensing
Applicable places: corridor, hallway, bathroom, living room, etc.
Package list:
Sensor switch* 1
1. Fresnel lens, high sensitivity, fast and stable response speed
2. Delay time and adjustable light sensitivity.
3. Preferred terminals, stable connection, easy and fast installation with ceiling mounting clips.
4.PC flame retardant material, effectively prevent fire hazards, high temperature resistance, long-lasting durability.
5. Wide range of use, compatible with incandescent lamps, energy-saving lamps, ceiling lamps, downlights, light strips, etc.
Product Parameters:
Product name: time-delayed infrared sensor probe
Working voltage: AC220V
Rated current: 4A
Load power: ≤ 40W, energy-saving lamps, LED lamps, fluorescent lamps, etc.
Mode setting: dark, dim, all day adjustable
Delay time: 3 seconds, 45 seconds, 4 minutes, adjustable
Sensing distance: 3-5 meters
Light sensitivity: 10LUX
Sensing principle: infrared human body sensing
Applicable places: corridor, hallway, bathroom, living room, etc.
Package list:
Sensor switch* 1
Embedded Installation
Specification:
Type: Motion Sensor light Switch
Color: White
Output form: SCR
Working voltage: wide voltage AC 85-265 (V)
Induction principle: infrared sensor
Output power:≤40W
Mode Setting: Deep Dark/light Dark/All day
Sensing Distance: 4-6m
Delay off time: 3 seconds 45 seconds 4 minutes
Angle Coverage: 110°
Extreme Temperature Using: -10 celsius-+45 celsius
Standby power consumption: <0.1W
Scope of application: interior decoration ect.
Specifications: Opening 26mm
Package included：
1*Motion Sensor light Switch
Type: Motion Sensor light Switch
Color: White
Output form: SCR
Working voltage: wide voltage AC 85-265 (V)
Induction principle: infrared sensor
Output power:≤40W
Mode Setting: Deep Dark/light Dark/All day
Sensing Distance: 4-6m
Delay off time: 3 seconds 45 seconds 4 minutes
Angle Coverage: 110°
Extreme Temperature Using: -10 celsius-+45 celsius
Standby power consumption: <0.1W
Scope of application: interior decoration ect.
Specifications: Opening 26mm
Package included：
1*Motion Sensor light Switch
