Details
2. High accuracy: adjustable output current signal range of 0mA-22mA, digital display to ensure high accuracy of operation.
3. Better safety: equipped with short-circuit protection and reverse protection, the current signal generator is very safe.
4. Widely used: can be applied to PLC panel debugging, equipment testing, inverter, servo motor speed control, etc.
5. Easy to install: light weight, compact size, easy to install the rail, can be completed in a few minutes.
DC24V
Supply voltage range:DC15V--DC28V
AC220V (optional) Power supply range: AC85-264V or DC110-370V
Power consumption <2w
Output current range: OmA---22mA (settable, factory setting 0-20/4-20mA)
Output regulation accuracy 0.1mA, error <0.05mA, load sampling resistance <500ohm
Working environment:0-40℃, relative humidity<80%
1 x Main unit
