YY High Speed Handpiece
Brand:BEING
Model:
Handpiece:
202SH: 1:1 Straight Handpiece
202SHB: Fiber Optic Straight Handpiece
202CAP: 1:1 Contra Angle Handpiece
202CAP-FG: FG1.6 1:1 Contra Angle Handpiece
202CAPB: 1:1 Fiber Optic Contra Angle Handpiece
202CAPB-FG: FG1.6 1:1 Fiber Optic Contra Angle Handpiece
202CAR4: 4:1 Reduction Contra Angle Handpiece
202CAR4-B: 4:1 Fiber Optic Reduction Contra Angle Handpiece
202CAR4-PS: 4:1 Prophy Handpiece
202CAR4B-PS: 4:1 Fiber Optic Prophy Handpiece
202ZI5-B: Increasing 1:5 Fiber Optic Handpiece
202CAI45-B: 45° Increasing 1:5 Fiber Optic Handpiece
202CAR16: 16:1 Reduction Contra Angle Handpiece
202CAR16B: 16:1 Reduction Fiber Optic Contra Angle Handpiece
202CAR20: 20:1 Reduction Contra Angle Handpiece
202CAR20B: 20:1 Reduction Fiber Optic Contra Angle Handpiece
CH-18L Intra Head 2.35mm
CH-18H Intra Head FG1.6mm
CH-18H Intra Head FG1.6mm
Air Motor:
202AM-M4: 4 Holes Air Motor NO LED
202AMB-M6: 6 Holes Air Motor LED
Description:
Rose-202SH:
- ISO E type straight handpiece
- 1:1 direct drive
- With internal cooling system
- Fit KaVo Style
- Chuck type: Latch type
- Use HP bur 2.35mm
- Speed: MAX 40,000rpm
Rose-202SHB:
- Fiber optic
- ISO E type straight handpiece
- With internal cooling system
- Chuck type: Latch type
- Use HP bur 2.35mm
- Speed: MAX 40,000rpm
Rose-202CAP:
- Inner water spray pipe
- Push button type, internal spray nozzle, ISO E type.
- Fit Kavo INTRAmatic Head, for Kavo contra angle.
- Air Pressure: 245-392Kpa(2.5-4.0 kgf/cm²)
- Water Pressure: 198Kpa (2kg)
- Rotation Speed: 22,000-27,000 rpm
- Chuck Type: Latch Type
- Bur Applicable: Φ2.334-2.355mm
- Noise: ≤70dB
Rose-202CAP-FG:
- Inner water spray pipe
- Push button type, internal spray nozzle, ISO E type.
- Fit Kavo INTRAmatic Head, for Kavo contra angle.
- Air Pressure: 245-392Kpa(2.5-4.0 kgf/cm²)
- Water Pressure: 198Kpa (2kg)
- Rotation Speed: 22,000-27,000 rpm
- Chuck Type: Latch Type
- Bur Applicable: Φ1.60mm
- Noise: ≤70dB
Rose-202CAPB:
- Fiber Optic, Inner water spray pipe
- Push button type, internal spray nozzle, ISO E type.
- Fit Kavo INTRAmatic Head, for Kavo contra angle.
- Air Pressure: 245-392Kpa(2.5-4.0 kgf/cm²)
- Water Pressure: 198Kpa (2kg)
- Rotation Speed: 22,000-27,000 rpm
- Chuck Type: Latch Type
- Bur Applicable: Φ2.334-2.355mm
- Noise: ≤70dB
Rose-202CAPB-FG:
- Fiber Optic, Inner water spray pipe
- Push button type, internal spray nozzle, ISO E type.
- Fit Kavo INTRAmatic Head, for Kavo contra angle.
- Air Pressure: 245-392Kpa(2.5-4.0 kgf/cm²)
- Water Pressure: 198Kpa (2kg)
- Rotation Speed: 22,000-27,000 rpm
- Chuck Type: Latch Type
- Bur Applicable: Φ1.60 mm
- Noise: ≤70dB
Rose-202CAR4:
- 4:1 reduction contra angle
- Slow Speed Handpiece
- Push Button head
- for 2.35mm LA RA Latch Burs
- Fit KaVo INTRAmatic style head
- Head exchangable for KaVo contra angle
Rose-202CAR4-B:
- Fiber Optic
- Internal Spray
- 4:1 reduction
- Push Button
- Fit KaVo INTRAmatic style head
- Bur applicable: Ф2.334-2.35mm
- MAX speed: Max 10,000rpm
Rose-202CAR4-PS:
- 4:1 Reduction
- Fit Kavo style INTRAmatic Connection, Screw in head. Use screw prophy cup or Prophy brush.
- For dental prophy polishing ( Hygiene handpiece )
- ISO E type, can be used with all ISO E type motor. for KAVO NSK W H BIEN AIR.
Rose-202CAR4B-PS:
- Fiber Optic
- 4:1 Reduction
- Fit Kavo style INTRAmatic Connection, Screw in head. Use screw prophy cup or Prophy brush.
- For dental prophy polishing ( Hygiene handpiece )
- ISO E type, can be used with all ISO E type motor. for KAVO NSK W H BIEN AIR.
Rose-202CAR16:
- 16:1 Reduction
- Intra Head
- Internal spray
- Push button type
- Bur applicable:2.334-2.35mm
- Speed: max 2500rpm
Rose-202CAR16B:
- Fiber Optic
- 16:1 Reduction
- Intra Head
- Internal spray
- Push button type
- Bur applicable:2.334-2.35mm
- Speed: max 2500rpm
Rose-202CAR20:
- 20:1 Speed Reduction Low Speed
- Implant surgery contra angle handpiece with internal cooling system, single water spray.
- Max rotation speed: 2,000rpm (With micromotor by max speed: 40,000rpm)
- Bur applicable: 2.334-2.35mm
- Noise ≤ 70d
- MAX Torque: 90N
Rose-202CAR20B:
- Fiber Optic
- 20:1 Speed Reduction Low Speed
- Implant surgery contra angle handpiece with internal cooling system, single water spray.
- Max rotation speed: 2,000rpm (With micromotor by max speed: 40,000rpm)
- Bur applicable: 2.334-2.35mm
- Noise ≤ 70d
- MAX Torque: 90N
Rose-202Z15B:
- 1:5 Fiber Optic Contra Angles
- 1:5 Speed up contra angle handpiece
- Internal cooling sysem
- triple water way spray
- Max rotation speed: 2000,000rpm (With micromotor by max speed: 40,000 rpm)
- Bur applicable: 1.59 - 1.6mm
Rose-202CAI145B:
- 45 Degree, 1:5 Fiber Optic Contra Angles
- 1:5 speed up contra angle handpiece
- Fiber Optic Contra Angle Handpiece
- 45° Angle Surgical / Surgery handpiece
- Internal cooling sysem
- triple water way spray
- Bur applicable: 1.59 - 1.6mm
- Max rotation speed: 2000,000rpm (With micromotor by max speed: 40,000 rpm)
- ISO E Type Connection fit for Electric Micro Motor with LED
Rose-202AM-M4:
- 4 Holes
- E type Air motor
- Fit Low Speed Handpiece
- Internal Cooling System
- Air Pressure: 245-392Kpa(2.5-4.0 kgf/cm²)
- Water Pressure: 198Kpa (2kg)
- Rotation Speed: 22,000-27,000 rpm
- Noise: ≤70dB
Rose-202AMB-M6:
- 6 Holes (6 Pin)
- Fiber Optic LED
- Internal water spray system
- E Type Low Speed Handpiece Air Motor 1:1
- Speed: 22000-27000rmp
- Noise: ≤70dB
