Tile Backer Board 6mm, 10mm, 20mm, 30mm Pack of Ten Boards 7.2 metres
6mm,10mm,20mm, and 30mm Tile Backer Board 10 Sheets
Tile Backer Boards are ideal for underfloor and under-tile heating installations and can be used on existing un-insulated concrete or timber sub-floors. They also greatly reduce heat-up time and running costs.
Tile Backer Boards are ideal for two reasons; an excellent waterproofing surface to fix either wall or floor tiles and as excellent heat insulation for underfloor heating systems.
Tile Backer Boards are also suitable for waterproofing wet rooms and showrooms and will protect the floor from absorbing water.
When installing onto concrete sub floors we recommend using flexible tile adhesive, when installing onto wooden floors we recommend using tile adhesive and/or screws and washers.
Sample Pack Includes:
6mm & 10mm Cement Board Sample - approx. 100mm x 150mm each
6mm & 10mm Cement Board Sample - approx. 100mm x 150mm each
6mm Impact Plus Insulation Sample - approx. 150mm x 200mm each
SF / HC / SP & Shower Liner Decoupling Sample - approx. 50mm x 120mm each
Loose Wire UFH Cable Spacer - approx. 160mm in length
1 x Cement Board Washer Disc
Underfloor Heating and Fixings for use with our Tile Backer Boards.
You May Also Require
Things to know about this product
Living Heat insulation is manufactured in compliance with BS EN ISO 9001:2001 and certified by BBA Certificate 04/4186. Living Heat insulation also complies with BS EN 13164: 2001 Thermal insulation products for buildings.
All boards come complete with an industry-leading 10 year, waterproof and structural integrity guarantee.
Boards measure (1200mm x 600mm) x 6mm, 10mm 20mm, or 30mm.
Boards can be installed with a suitable adhesive or screwed in position with insulation washers, (both available separately from Living Heat).
Please note when using insulation fixing washers, the washers should be fixed at a maximum of 300mm centres which means you will need at least 15 washers per board.
Please feel free to call us if you have any questions or require further assistance. Our time and advice are Free.
| For Use With |
|---|
| All types of electric and water underfloor heating systems |
| On top of concrete and timber sub floors |
| Under all ceramic, porcelain, natural slate and stone floors |
| For use on walls and floors, ideal for wet rooms |
| Characteristics Include |
|---|
| High thermal insulation capacity, (blocks out the cold) |
| Totally inert, (does not degrade with time or external conditions) |
| Light easy and safe to handle |
| Easy to cut with sharp knife / fine tooth saw |
| Resistant to tile cement, building cement and most other building compounds |
| Water and damp proof |
| High compression ratio. (minimum 40 tonnes, (yes tonnes!) per m 2) |
| Environmentally friendly |
| dimensionally stable, (will not twist or buckle when exposed to moisture or heat) |
| Excellent sound insulation, (reduces sound reverberation / impact sound) |
| In Detail | ||
|---|---|---|
| Thermal Conductivity W/mK | 0.027 | Prevents heat loss |
| Thermal Resistance sqmK/W | 0.85 | Blocks out cold |
| Fire Protection Class | Bs 3837 | B1 DIN British Standard |
| Compression strength KPa 25% | 400 | A minimum of 40 metric tonnes, (yes tonnes!) can be placed on 1 m 2 without damage |
| Water penetration (96 hours) | 0.00 | Waterproof |
