Overview

R80L is a multimode RS232 GNSS receiver with built-in ubx neo-m8n module (M8030 chip) and built-in 4M flash to support configuration and permanent saving of configuration. The UBX-M8030 high performance standard precision GNSS chips from u-blox provide exceptional sensitivity and acquisition times for all GNSS systems. The chips utilize concurrent reception of up to three GNSS systems (GPS/Galileo together with either Beidou or GLONASS). Reception from more than one constellation simultaneously allows extraordinary positioning accuracy in urban canyons, even with weak signals and high dynamics. ​The accuracy reaches 1.5m cep，and the average cold start time is 25s.It also has built-in small battery to support receiver hot start.It is widely used in agriculture,Industry,car navigation, sea navigation, ranging, automatic driving, etc. ​Highlights: ​• Concurrent reception of up to 3 GNSS (GPS, Galileo, GLONASS, BeiDou) ​• Industry leading –167 dBm navigation sensitivity ​• Industry lowest current consumption ​• Superior position accuracy in urban canyons ​• Security and integrity protection ​• Support for all satellite augmentation systems
