2PCS New WLN KD-C1plus mini Walkie Talkie KD-C1 plus UHF 400-520MHz slim transceiver two way radio KD-C1 Upgraded



Comparison of  WLN KD-C1 and KD-C1PLUS

Feature:

50 CTCSS/105 CDCSS

VOX Function

Voice Prompt

PC Programming

Emergency Alarm

Intelligent Charging

Battery Save

Low Voltage Alert

Time-out Timer



Specification:

General Specifications
Frequency Range	UHF 400-470MHz
Channel Capacity	16
Channel Spacing	25KHz
Operated Voltage	3.7 V
Battery	1500MAh Li-ion
Battery Life(5-5-90 duty cycle) About 8 hours
Frequency Stability	±2.5ppm
Operated Temperature	-30°c-+60°c
Antenna Impedance	50Ω
Dimensions (L×W×H) (with battery,without antenna)	110×50×32 mm
Weight (with battery/antenna)	125g
Communication Range	about 6km
Transmitter
RF Power Output Modulation	<5W F3E
Spurious Emission	≤65dB
FM Noise	≤-45dB(W) ≤-40dB (N)
Audio Distortion	≤5%
Transmitting Current	≤1.3A
Receiver
Sensitivity (12dB SINAD)	≤0.20 uV
Selectivity	55dB/50dB
Intermodulation	≥65dB
Adjacent Channel Selectivity ≥60dB
Spurious Response	≥60dB
FM Noise	45dB/40dB
Audio Power Output	1000mW
Audio Distortion	≤5%
Standby Current	≈15mA (with battery save on)
