✨Product Principles: LED curing light uses the principle of light radiation, the photosensitive resin was cured by irradiation.
✨Application: Suitable for dental clinical irradiation of polymer-based repair materials to solidify.
✨Two Working Modes: P1 Highlight mode, P2 Standard mode.
✨Time setting: 1/3/5/10/15/20/25s.
✨High Capacity Battery: A full charge can be used for more than 400 times continuously under 10s working time mode.
✨Low standby power consumption with seventy days standby time.
| 1 sec | 1 sec | 5 sec | 5 sec |
| Light Intensity |
P1: 2000-2500mw/cm2 P2: 1000-1200mw/cm2 |
Light Intensity |
P1: 1400-1800mw/cm2 P2: 1000-1400mw/cm2 |
| Model | LV7 | Model | LV5 |
| Name | 1 SEC LED Curing Light | Name | 5 SEC LED Curing Light |
| Material | ABS | Material | ABS |
| LED Lamp Power | ≤5W | LED Lamp Power | ≤5W |
| Power Source Output | DC 5V/1A | Power Source Output | DC 5V/1A |
| AEL | 3.9*10-3J | AEL | / |
| Wavelength | 385nm ~ 515nm | Wavelength | 420nm ~ 480nm |
| Optical Effective Area | 50mm² | Optical Effective Area | 50mm² |
| Power Source Input | ~100V-240V, 50Hz/60Hz, 0.4A(Max) | Power Source Input | ~100V-240V, 50Hz/60Hz,0.4A(Max) |
| Color | Blue, Red, Black | Color | Blue, Red, Black |
✈️1 X Dental Curing Light
✈️1 X Light Guide
✈️1 X Light Barrier
✈️1 X Bracket
✈️1 X Power Adapter
