Features：
1. Use of high quality materials, durable
2. Slim type power display, 5 LED indicators, more intuitive display, more beautiful
3. With reverse connection function, even if the positive and negative connection will not burn
4. Compact and exquisite appearance
5. Use a wider range of lithium batteries, lead-acid batteries, lithium iron phosphate, electric car batteries, electric equipment can be used

Specifications：
Allowable error: ±2%.
4 sections of power: 25% 50% 75% 100%
Operating current: 15ma
Lead wire length: 15cm
Dimension: 40x 15x 2.5mm
Net weight: 8g
Operating temperature: -10℃~65℃

Installation.
1. Connect the positive and negative terminals of the display board to the positive and negative terminals of the battery under test, lightly press the red button with your finger, the IED light will light up to show the real-time battery level.
2. Release your finger, the LED light will go out after a delay of 3-10 seconds, no power consumption at all when static.
3. With reverse connection function, even if the positive and negative connection will not burn, adjust it over

Lithium battery pack display power parameters: (the following data is a reference value, there will be 2% error range, do not shoot if you require high accuracy)

Warm tip: 3.7V lithium battery with a red power indicator, 4 green power indicator (other voltage range is a red power indicator, 4 blue power indicator)
(Note: N is the number of battery sections)
First power indicator is red
Battery voltage greater than N x 3.3V, 2nd blue light
Battery voltage greater than N x 3.5V, 3rd blue light
Battery voltage greater than N x 3.7V, 4th blue
Battery voltage greater than N x 3.9V, light up the 5th blue

Package list：
Power indicator*1
