Screw Machine Fully Automatic KLD-V5 Digital Display Counting Handheld Feeder Screw Supply Arrangement Feeder Small

Product Specifications
Product Name: Automatic Screw Feeder
Counting Capacity: Up to 9,999
Input Power: AC 110-240V, auto-adaptive
Dimensions: 125 x 180 x 150 mm
Machine Weight: Approx. 3.5 kg
Track Width: 1.0-5.0 mm
Screw Length: Less than 20 mm
Screw Type: Screws with nuts and without washers

Description:

In the screw machine industry also called screw machine, screw arrangement machine, screw feeder, etc.
Mainly to simplify the workers in the process of traditional screw lock pay process operation process, reduce the labor intensity of workers and development design.
Main function is to screw lined up sent to the specified location, directly by the email operator of picking, simplify the traditional lock pay action, improve production efficiency.
Widely used in electronic industry, compared with the traditional screw plate, extract each screw can save 1.4 seconds, so the production efficiency can be improved by 4 times.

Feature:

1.Length can be made of M0.8 to M5 (< 20 mm) between any specifications, the reasonable adjustment, BuKa material.
2.Can use ordinary screw, flat head screws with washers screw, tapping screw and so on many kinds of screws, consult the seller don't understand.
3.Orbital size adjustment easy, cooperate with screw size, whether in cm or inch specifications, are able to operate freely.
4.A machine can adjust out of a variety of specifications using screw, the user can reduce the cost of equipment procurement.
5.Seismic distance is small, strong vibration, screw arrived at the front end point, not running forward and obvious effect to the speed of the screw and the production speed.
6.Send material and the driving mode of vibration independence, are free to set the ideal stop time, will not cause mutual interference and influence the normal function.Screw roller rolling blanking you then, arriving at the front of the vibration time, screw speed in orbit, performed with single-chip microcomputer control, time to cooperate with production line homework.Machine adopts 110-240 - v AC voltage input, dc 12 v power supply output voltage stability, provide the correct voltage, makes the machine can be used anywhere in the world and it works, will not be affected by the input voltage is too high or low.
