FEATURES:

1.meglev generator

2.2 blades

3.20years use life and 1 year for warranty

4.small ,light ,stable and safely

5.Certified with:CE

6.High efficiency, could be hybrid system with solar panels.

7. Applications: Marine, Boat,Streetlights, Home, Openning Plaza lighting..



Rated power: 2000w

Rated voltage: 24/48/96/120/220V

Blade length: 150 cm

Top net weight: 38kg

Wind turbine diameter: 0.67 m

Rated wind speed: 12m / s

Starting wind speed: 1.8 m / s

Survival wind speed: 40m / s

Generator: 3-phase permanent magnet synchronous generator

Lifespan: More than 20 years

Warehouse: HRB or for your order

Blade material: glass basalt

Shell material: aluminum alloy

Permanent magnet material: rare earth NdFeB

Control system: electromagnet

Lubrication: grease

Working temperature: -40 to 80



 PACKING LIST:

2 pcs blades ,1 set generator and 1 set bolts &nuts.
main shaft 1 piece.
DN40 FLANGE


Wind Turbine for off grid system:

The wind turbine voltage should be same as your battery voltage!

 BECOME ENERGY SELF-SUFFICIENT Living off the grid and being self-sufficient feels good. For some people, this feeling is worth more than saving money. Energy self-sufficiency is also a form of security. Power failures on the utility grid do not affect off-grid wind systems. On the flip side, batteries can only store a certain amount of energy, and during cloudy times, being connected to the grid is actually where the security is. You should install a backup generator to be prepared for these kinds of situations.

System Connection Sequence：
1. Charge controller connect to battery
2. Charge controller connect to wind turbine
Please note that when battery is full charged or run out, the charge controller will brake the wind turbine automatically
