Package: Nema 23 3Nm Motor +Driver+Power Supply
- 1 x Nema 23 Closed Loop Stepper Motor 3.00Nm(424.83oz.in) Encoder 1000PPR(4000CPR)
- 1 x Closed Loop Stepper Driver 0-7.0A 24-50VDC for Nema 17, 23, 24 Stepper Motor
- 1 x 201W 36V 5.9A 115/230V Switching Power Supply
Package: Nema 34 6.5Nm Motor +Driver+Power Supply
- 1 x Nema 34 Closed Loop Stepper Motor 6.50Nm(920.48oz.in) Encoder 1000PPR(4000CPR)
- 1 x Closed Loop Stepper Driver 0-8.5A 20-80VAC/30-110VDC for Nema 34 Stepper Motor
- 1 x 350W 60V 5.8A 115/230V Switching Power Supply
Package: Nema 34 12Nm Motor +Driver+Power Supply
- 1 x Nema 34 Closed Loop Stepper Motor 12.00Nm(1699.34oz.in)Encoder 1000PPR(4000CPR)
- 1 x Closed Loop Stepper Driver 0-8.5A 20-80VAC/30-110VDC for Nema 34 Stepper Motor
- 1 x 350W 60V 5.8A 115/230V Switching Power Supply
Nema 23 3Nm Motor Specification
- Manufacturer Part Number: 23HS40-5004D-E1K-1M5
- Motor Type: Bipolar Stepper
- Step Angle: 1.8deg
- Holding Torque: 3.00Nm(424.83oz.in)
- Rated Current/phase: 5.0A
- Phase Resistance: 0.7ohms ± 10%
- Inductance: 2.3mH ± 20%(1KHz)
- Insulation Class: B 130°C[266°F]
- Frame Size: 57 x 57mm
- Body Length: 122mm
- Shaft Diameter: Φ8mm
- Shaft Length: 22mm
- D-Cut Length: 15mm
- Cable Length: 1500mm
Nema 34 6.5Nm Motor Specification
- Manufacturer Part Number: 34HS39-6004D-E1K-1M5
- Motor Type: Bipolar Stepper
- Step Angle: 1.8deg
- Holding Torque: 6.50Nm(920.48oz.in)
- Rated Current/phase: 6.0A
- Phase Resistance: 0.43ohms ± 10%
- Inductance: 2.6mH ± 20%(1KHz)
- Insulation Class: B 130°C[266°F]
- Frame Size: 86 x 86mm
- Body Length: 120mm
- Shaft Diameter: Φ14mm
- Shaft Length: 37mm
- Keyway Shaft Length: 25mm
- Cable Length: 1500mm
Nema 34 12Nm Motor Specification
- Manufacturer Part Number: 34HS59-6004D-E1K-1M5
- Motor Type: Bipolar Stepper
- Step Angle: 1.8deg
- Holding Torque: 12.00Nm(1699.34oz.in)
- Rated Current/phase: 6.0A
- Phase Resistance: 0.59ohms ± 10%
- Inductance: 4.8mH ± 20%(1KHz)
- Insulation Class: B 130°C[266°F]
- Frame Size: 86 x 86mm
- Body Length: 174mm
- Shaft Diameter: Φ14mm
- Shaft Length: 37mm
- Keyway Shaft Length: 25mm
- Cable Length: 1500mm
Encoder Specification
- Output Circuit Type: Differential type
- Encoder Type: Optical Incremental
- Encoder Resolution: 1000PPR(4000CPR)
- Output Signal Channels: 2channels
- Supply Voltage Min: 4V
- Supply Voltage Max: 5V
- Output Current: 100mA
- Output High Voltage: 5V
- Output Low Voltage: 4.5V
- Output Frequency Max: 60kHZ
Motor and Encoder Connection
|
A+
|
A-
|
B+
|
B-
|
|
Black
|
Green
|
Red
|
Blue
|
|
PIN
|
Black
|
Red
|
White
|
Yellow
|
Green
|
Blue
|
|
Encoder
|
EA+
|
VCC
|
GND
|
EB+
|
EB-
|
EA-
|
Driver Specification
201W 36V Power Supply
- Part Number: LE-201-36
- Input Voltage: 115/230VAC±20%
- Input Frequency: 47-63Hz
- Input Current: 40A/230VAC
- Output Voltage: 36V
- Output Current: 5.9A
- Rated Output Power: 201W
- Leakage Current: <0.5mA/230VAC
- Dimensions: 215*115*30mm(L*W*H)
- Internal EMI filter
- High efficiency low cost
- Forced air cooling by built-in DC fan
- Over current, over voltage, short circuit and overheat protections
350W 60V Power Supply
- Part Number: LE-350-60
- Input Voltage: 115/230VAC±20%
- Input Frequency: 47-63Hz
- Input Current: 40A/230VAC
- Output Voltage: 60V
- Output Current: 5.8A
- Rated Output Power: 350W
- Leakage Current: <0.5mA/230VAC
- Dimensions: 215*115*30mm(L*W*H)
- Internal EMI filter
- High efficiency low cost
- Forced air cooling by built-in DC fan
- Over current, over voltage, short circuit and overheat protections
