Package Include
1 X AA5052 Aluminum Radiator1 X AA5052 Aluminum Shroud
2 X 14" Fans (Includes mounting kits)
1 X Thermostat Relay Kit
Radiator Size
Row: 3 Row Core
Material: AA5052 Aluminium
Core and Tank: AA5052 Aluminum
Core Size: 30 1/2" W x 17 1/4" H
Overall Size: 35 2/3"W x 18 3/4"H
Inlet Size : 1 1/4" Driver Side
Outlet Size: 1 1/4 "Passenger Side
Transmission Cooler：YES
Engine Oil Cooler: YES
Transmission: Automatic
Upgrade Performance
1.Made from Aircraft AA5052 grade aluminum for prolonged lifespanand with raw aluminum finish
2.Brazed core technology to guarantee optimum performance and dependability
3.All AA5052 Aluminum 2mm thick tanks and fittings,Ensure it's hard and durable
4.OEM style brass petcock drain much better than other plastic one on eBay
5.Carefully crafted to exceptional OE standards for precise fit.
FAN Specification:
Maximum Fan CFM: 1730 cfm
Fan Diameter (in): 14.050"
Thickness (in): 2.500"
Number of Blades: 8 S-Type blades
Blade Material: Plastic
Amp Draw: 12.70 amps
Includes the Mounti
Number of Blades: ng Tabs for an Easy Zip Tie Installation
Thermostat Kit Installation:
Universal fit for any automotive vehicle and electric fan.
Activates by grounding electric fans at preset temperature.
185'F turn-on temperature, 165'F turn-off temperature.
RED + connect directly to battery.
WHITE wire to ignition switch power source.
BLACK goes to thermos switch.
BLUE wire goes to the Fans.
This set up will run Fans & pull air in through radiator.
Year Make Model Engine
1994 Buick Commercial Chassis 5.7l V81994 Buick Roadmaster 5.7l V8
1994 Cadillac Commercial Chassis 5.7l V8
1994 Cadillac Fleetwood 5.7l V8
1994 Chevrolet Caprice 4.3l V8
1994 Chevrolet Caprice 5.7l V8
1994 Chevrolet Impala 5.7l V8
1995 Buick Commercial Chassis 5.7l V8
1995 Buick Roadmaster 5.7l V8
1995 Cadillac Commercial Chassis 5.7l V8
1995 Cadillac Fleetwood 5.7l V8
1995 Chevrolet Caprice 4.3l V8
1995 Chevrolet Caprice 5.7l V8
1995 Chevrolet Impala 5.7l V8
1996 Buick Commercial Chassis 5.7l V8
1996 Buick Roadmaster 5.7l V8
1996 Cadillac Commercial Chassis 5.7l V8
1996 Cadillac Fleetwood 5.7l V8
1996 Chevrolet Caprice 4.3l V8
1996 Chevrolet Caprice 5.7l V8
1996 Chevrolet Impala 5.7l V8
