12V Heavy Duty Linear Actuator - 660lbs/3000N 0.2"/s Speed for High‑Load Automation & DIY Equipment

Product Description

【Specification】

  • Voltage: DC 12V
  • Stroke length: 2"-40"
  • No load speed: 0.2"/sec (5mm/s)
  • Maximum load: 660lbs (3000N)
  • Maximum current draw: 5A
  • Working power should reach 40W-50W
  • Power cord length：1m

【Sturdy & Safe】

With high-quality aluminum alloy and four-corner fixation base design, make linear actuator have better stability and load-bearing capacity.With self-locking function and built-in limit switch, it can be stopped at any position and automatically stop at the top and the bottom, providing reliable and safe operation.

【Fast & Quiet Motion】

The linear actuator is equiped with high speed motor which make the travel speed up to 0.2"/sec.The linear actuator adopts high-strength plastic worm gear with more quiet and durable, not easy to oxidize, noise below 50dB.

【Application】

With IP65 protection, suitable for home and outdoor use. It can be widely used in door opener, electric bed, electric sofa, electric lifting lever, electric booth, electric sunroof, marine & RV applications, solar tracker and so on.

【Package Included】

  • 1 × Black Linear Actuator Motor
  • 2 × Mounting Bracket
  • 1 × 12V Power Supply(Optional)
  • 1 × Remote Controller(Optional)

【Details】

Linear Actuator：

  • The linear actuators are controlled by applying a 12V DC voltage, basically, connect the two wires to a 12 volt battery.
  • Reversing the polarity will make the actuator reverse.
  • Red wire to the positive terminal and black wire to negative terminal will make it extend. To make it retract, reverse the terminal connections.
  • The actuator has pre-installed limit switche inside, it cannot be adjustable.

Remote Controller：

  • 【Basic Information】Working voltage DC 12V , It is specially designed for DC 12V linear actuator.It can control your actuator to move forward & reverse more easily.
  • 【Remote Control Distance】Without doors and walls blocking,remote control distance up to 230 feet / 70 meter.
  • 【Easy to use】Press the up button linear actuator move forward, press the down button linear actuator move backward. Press the middle button,linear actuator stop moving.
  • 【Stable & Safe】The wireless remote controll with high receive sensitivity and more stable.Made of the ABS material and flame retardant material,more safer.
12V Power Supply：
  • 【Basic Information】Input voltage: AC100-240V; Input voltage frequency: 50-60Hz; Output voltage: 12V; Output current: 5A.
  • 【Stable & Safe】The power adapter has protective functions,with overcurrent protection, short circuit protection, and overheating protection.
  • 【Easy to use】Simply connect the adapter to the linear actuator, then insert the power plug.
  • 【Suitable for】The power adapter is design for DC 12V linear actuator.
