NEW Powerhobby ARX-471R 2.4G T-FHSS HV 4-Channel Receiver Futaba Radio Compatible

Powerhobby ARX-471R 2.4G T-FHSS HV 4-Channel Receiver Futaba Radio Compatible

Description

The PowerHobby ARX-471R is a compact 2.4GHz 4-channel receiver designed for compatible Futaba T-FHSS surface radio systems. Its high-voltage design supports an operating range of 3.5V to 8.4V, making it suitable for standard receiver power systems and compatible 1S or 2S LiPo setups.

The receiver features bidirectional communication, allowing compatible transmitters to monitor receiver voltage in real time. A built-in high-sensitivity antenna provides a clean installation without an exposed antenna wire.

Features

Compatible with Futaba T-FHSS surface radio systems
Four standard channels plus S.BUS2 support
Bidirectional communication
Real-time receiver-voltage monitoring with compatible transmitters
High-voltage 3.5V to 8.4V operating range
Compatible with 1S and 2S LiPo receiver power
Built-in high-sensitivity antenna
Normal and high-speed PWM modes
Compact and lightweight design
Suitable for RC cars, trucks, crawlers, and other surface vehicles

Specifications

Frequency: 2.4GHz
Protocol: T-FHSS
Channels: 4CH plus S.BUS2
Operating Voltage: 3.5V–8.4V
PWM Modes: Normal and High Speed
Dimensions: 23.6 × 18.4 × 28.4mm
Weight: 7.3g
Part Number: PHBPHARX471R

Includes

1 PowerHobby ARX-471R 4-Channel Receiver

Compatibility

Compatible with Futaba surface transmitters operating in T-FHSS mode. The product compatibility list includes:

Futaba 3PV
Futaba 4PV
Futaba 4PM
Futaba 4PL
Futaba 4PX
Futaba 7PX
Futaba 7PXR

Confirm that your transmitter supports the required T-FHSS protocol before ordering. This receiver is PowerHobby branded and is not manufactured by Futaba.
