Tiptop Audio Zeus Power Bundle - 6U

The TipTiptop Audio Zeus Power Bundle, is a great solution for those looking for studio quality power for their eurorack modules. The 6U bundle comes with:

- 1 x Zeus Access
- 2 x Studio Bus
- 1 x Cincon power brick
- 1 x set of hook up wires

Zeus Access
The Tiptop Audio Zeus Access is a 4HP front panel that provides a simple solution for linking up to three Zeus Studio Bus. It comes fully assembled and wired with 16AWG wire and plated copper terminals leads that require no additional assembly or special tools for connecting to a Tiptop Audio Zeus Studio Bus.

Zeus Studio Bus
The Zeus Studio Bus offers a total of 16 module connectors, 14 of them are 16-pin headers for connecting eurorack modules and two of the connectors are for analogue system modules. The additional 5V voltage needed by some modules is being generated internally by the Zeus Studio Bus. Three LEDs show the active voltages 12V, -12V and 5V. The maximal current per bus board is 1250mA at 12V, 800mA at -12V and 300mA at 5V.

Power Supply:
2500mA +12v
1600mA -12v
600mA +5V.

Cincon Power Brick
Cincon-TTA power supply is the power unit and can run up to three Zeus Studio Bus’. The switching power supply works with 110v to 230v. The Cincon power supply will be supplied with a 13 amp mains lead.
