40IDF Carburetor W/ Air Horn for VW Beetle for Fiat for Porsche

Application:

For VW Bug Beetle
For Fiat
For Porsche carburetor with Air Horn

For Dual Application

Carburetor for modification with Any application that utilizes for 40 IDF carburetor.

Specifications:

Barrel Count:  2
for Part Number: 40 IDF
Throttle Throat Size: 40 mm
for Main Jet: 115
Emulsion Tubes: F11, F-11
for Air Corrector Jet: 200
for Idle Jet: 52
for needle & seat: 200
for Accelerator Pump Jet: 50
for Pump Exhaust Jet: 550
Venturis: 28 mm
Auxiliary Venturi: 4.5 mm
Needle Valve: 1.75 mm
Bolt Hole Spacing (Length & Width): 134.5mm (max)×64 mm (max)  ( center to center )
Choke Air Horn Inner Diameter: 46 mm
Choke Air Horn Outer Diameter: 65 mm
Material: Heavy Duty Zinc Alloy Construction
Placement On Vehicle:  Front

Warranty:2 years

Note:
*Please allow 1-2mm error due to manual measurement.
* Please check the measurement information of the carburetor to ensure you are ordering the correct part.

Package includes:

2x Carburetor with air horn

4x Mounting gaskets

Exactly as picture shows.

Features

1.To mix air and gasoline in a correct ratio to ensure proper engine function, Give your machine the new power it deserves.

2. Add 5~10% horsepower and maintain near stock fuel mileage.

3. Brand new and high quality carburetor replacement part. Helpful for avoiding waste of oil to some extent.

4. Profiled gas (butterfly) waves, cold start circuit eliminated for a 20% larger float bowl & more fuel volume

5 Specially designed and tested to exact OEM standards, Easy installation with mounting gasket.

6 Aftermarket high performance engine carburetor replacement

7. Nickel plating surface to keep the carb last much longer

Description

1. Carburetor structure: Components of Carburetor usually include a storage chamber for liquid fuel, a choke, an idling (or slow-running) nozzle, a main nozzle, a venturi-shaped air-flow restriction, and an accelerator pump. The quantity of fuel in the storage chamber is controlled by a valve actuated by a float.

2. Carburetor is a kind of oil supply device in the engine of automobile，The goal of a carburetor is to mix just the right amount of gasoline with air so that the engine runs properly.

3. Function: Add more horse power while maintaining near stock fuel mileage

4.Carburetor cleaning process:
(1) First remove the carburetor from the car
Turn off the oil and unplug the oil pipe. Twist out the nut connecting the carburetor and the engine with a quincunx or quincunx (depending on the size of the nut), and then twist out the screw that connects the carburetor to the filter. Finally, remove the throttle cable. Turn off. Oil, unplug the oil pipe.
(2) Remove the carburetor float chamber
Use a cross knife to twist out the three screws of the carburetor float chamber cover
(3) Understand the carburetor
After disassembling the carburetor, let’s get to know the names of its parts
(4) Decompose the various parts of the carburetor
Remove the main fuel injection hole, idle fuel injection hole and float of the carburetor
(5) Start cleaning the carburetor
Use the carburetor cleaning agent to aim at each measuring hole and spray (note that the eyes should not be aimed at the carburetor, so as not to spray the cleaning agent into the eyes)
(6) Install carburetor
After cleaning, the carburetor can be installed. Then you can load him into the car.
