Product Overview
This listing is for a brand-new aftermarket PMDD starter motor supplied by Power Source Parts for select Kawasaki and Suzuki street motorcycle applications.
This starter is primarily cataloged under the Lester 18828 / 18828N family. Depending on the manufacturer or aftermarket catalog, compatible Suzuki applications may also be listed under the Lester 18788 / 18788N family.
The starter features a 12-volt PMDD design, 0.6 kW output, counterclockwise rotation and a 10-tooth drive. It is designed to replace the Kawasaki, Suzuki and Denso starter numbers listed in this description.
Manufactured to provide dependable starting performance and proper compatibility with the applications, specifications and OEM reference numbers shown below.
Starter Specifications
| Product Type | Motorcycle Starter Motor |
| Condition | Brand New Aftermarket Unit |
| Starter Design | PMDD - Permanent Magnet Direct Drive |
| Voltage | 12 Volt |
| Power | 0.6 kW / Approximately 0.805 HP |
| Rotation | Counterclockwise / CCW |
| Number of Teeth | 10 |
| Gear Outside Diameter | Approximately 0.512 in. / 13 mm |
| Overall Length | Approximately 5.642 in. / 143.3 mm |
| Register Diameter | Approximately 1.181 in. / 30 mm |
| Mounting | 2-Bolt Mounting / Approximately 6.6 mm Unthreaded Holes |
| Battery Terminal | M6 B+ Stud |
| Mounting Hardware Included | No |
| Primary Lester Reference | 18828, 18828N |
| Additional Lester Reference | 18788, 18788N |
Important Fitment Notice
Please verify your original OEM starter number, motorcycle model, production year, engine size, rotation, tooth count, mounting configuration and electrical-terminal position before ordering. Matching your original OEM or Denso number is the most reliable method of confirming compatibility.
Quick Fitment Summary
Kawasaki & Suzuki Fitment Guide
This starter motor is listed for the following Kawasaki and Suzuki street motorcycle applications:
| Make | Model | Years | Engine | Configuration |
| Kawasaki | ZX900 Ninja ZX-9R | 1998-2003 | 899cc | Inline-4 |
| Suzuki | GS500E | 1989-2002 | 487-497cc | Parallel-Twin |
| Suzuki | GS500 | 2001-2002 | 487cc | Parallel-Twin |
| Suzuki | GS500F | 2004-2009 | 487cc | Faired Parallel-Twin |
| Suzuki | GSX-R750 | 1988-1992 | 749cc | Inline-4 |
| Suzuki | GSX750F Katana | 1989-1997 | 748cc | Inline-4 |
18828N OEM & Interchange Numbers
This starter replaces or cross-references with the following Kawasaki, Suzuki, Denso and aftermarket numbers:
| Kawasaki | 21163-0017, 21163-1283, 21163-1288 |
| Kawasaki Without Dashes | 211630017, 211631283, 211631288 |
| Suzuki | 31100-20C00, 31100-20C01, 31100-27A01-H17 |
| Suzuki Without Dashes | 3110020C00, 3110020C01, 3110027A01H17 |
| Denso | 128000-6290, 128000-6800, 228000-7040 |
| Denso Without Dashes | 1280006290, 1280006800, 2280007040 |
| Lester | 18828, 18828N, 18788, 18788N |
| Arrowhead | 410-52569 |
| MES - Marine Electric Suppliers | ME1304-NA, ME1304NA |
| Stockers Starters | SS-13 |
| Road Warrior | 18788N |
18788N Cross-Reference Information
This listing is centered on the Lester 18828N catalog family. Compatible Suzuki applications may also be identified under Lester 18788 or 18788N, depending on the manufacturer, distributor or catalog being referenced.
Suzuki OEM numbers 31100-20C00, 31100-20C01 and 31100-27A01-H17, along with Denso number 128000-6290, are included as part of this combined interchange family.
Always compare your original part number and starter configuration before installation.
Part Number Verification
Some OEM and aftermarket catalogs display part numbers with dashes, while others display the same numbers without punctuation. Both formats are provided above to make identification easier.
No supersession claim should be assumed solely from the order in which the Kawasaki numbers are listed. Please verify your original number and motorcycle application before purchase.
Fast Nationwide Fulfillment
Power Source Parts is built around fast, reliable order handling and a methodical logistics process designed to get your order moving quickly. We focus on timely fulfillment, careful packaging and dependable service from checkout to delivery.
Orders received and paid before 1:00 PM Eastern Time typically ship the same business day whenever possible.
Power Source Parts Logistics Network
Power Source Parts is committed to fast, dependable order fulfillment through a strategically managed logistics network designed to efficiently serve customers throughout the United States.
Power Source Parts Lifetime Warranty
This starter is backed by our Power Source Parts Lifetime Warranty against manufacturer defects.
- Warranty covers replacement of the part due to a manufacturer defect.
- Warranty does not cover misuse, improper installation, abuse, alteration, water damage or damage caused by an incorrect application.
- Buyer is responsible for verifying correct fitment before installation.
- Please contact us through eBay messages if you need help confirming compatibility.
Shipping & Returns
Same Day Shipping
Orders placed and paid before 1:00 PM Eastern Time ship the same business day whenever possible. Orders placed after the cutoff, on weekends or on holidays will ship the next business day.
30 Day Free Returns
We offer 30-day free returns on eligible items. The item must be returned in the same condition received. Installed, damaged, altered, modified or incorrectly installed items may not qualify for a full refund.
Send us your original OEM starter number, motorcycle model, year, engine size and pictures of your original unit through eBay messages before ordering.
Compatibility information is provided as a guide only. Buyer must verify the original part number, specifications, mounting style, tooth count, rotation, terminal style and application before purchase. Brand names and part numbers are used for identification and interchange-reference purposes only.
