Epever MPPT Solar Charge Controller,Tracer-AN Series.

60A,12V/24V/36V/48VDC Auto,

Max 150V or 200V  PV Input,with LCD display.

Model: Tracer6420AN，Tracer6415AN

Overview:

Tracer-AN series controller, based on multiphase synchronous rectification technology (MSRT) and advanced MPPT control algorithm, with dual-core processor architecture and common negative design, has the features of high response speed, high reliability and high industrial standard. MSRT can guarantee very high conversion efficiency in any charge power, which sharply improves the energy efficiency of solar system; Advanced MPPT control algorithm minimize the maximum power point loss rate and loss time, to ensure the tracking efficiency, corresponding speed as well as high conversion efficiency under high or low power, so that in any situation, Tracer-AN products can rapidly track the maximum power point(MPP) of PV array to obtain the maximum energy of the panel. The limitation function of the charging power and current, and automatic power reduction function fully ensure the stability when works with oversize PV modules and operate under high temperature environment.

With the adaptive three-stage charging mode based on digital control circuit, Tracer-AN series controllers can effectively prolong the life-cycle of battery and significantly improve the system performance. The load, utility and generator auto-control relay output make it easy to connect other equipment. All-around electronic protections, including overcharging, over discharging, and PV reverse polarity protection, effectively ensure the safer and more reliable operation of the solar system for a longer service time. The isolated RS485 interface with standard MODBUS communication protocol makes it easy for customer to expand the application, greatly meet with different monitoring requirements, so that can be widely used for various applications, e.g. solar RV, household system and field monitoring, etc.

• About items

• Negative Ground 150V/200V PV Input, Compatible with 12/24/36/48V Batteries (Lead Acid) Charging.Lithium Battery :LiFePO4/ Li(NiCoMn)O2. Only Solar Panel and Battery Connector Available

• Dual RS485 Port (RJ45 Connector), it can be paralleled up to 8 units together linked by 8pin ethernet cable to make the data monitoring easy and accurate.

• Support 4 charging options: Sealed, Gel, Flooded and User define, Battery temperature compensation will make the charging progress efficiently.

• Standard Modbus communication protocol with RS485 interface , to monitor or set the parameters by using the phone Apps, MT50 Meter and PC software

•


• Product Feature

• Advanced MPPT technology & ultra-fast tracking speed, with tracking efficiency no less than 99.5%

• Maximum DC/DC transfer efficiency is as high as 98.6%, full load efficiency is up to 98%

• Advanced MPPT control algorithm will minimize the MPP loss rate and loss time

• The accuracy of the recognition and tracking at the highest point of multiple-peaks MPP

• Charging power and current limitation

• High-temperature charging power derating function

• Standard Modbus communication protocol with RS485 interface

• Negative Grounding Design

• 150V/200V PV input allows more panels connected in series

• Support up to 8 units paralleled

•


• Electrical Parameters:

  Item	Tracer6415AN	Tracer6420AN
  Nominal System Voltage	12/24/36/48VDC or Auto
  Battery Input Voltage Range	8V～68V
  Battery Type	Sealed/Gel/Flooded/User
  Rated charge current	60A	60A
  Rated charge Power	750W/12V	750W/12V
  	1500W/24V	1500W/24V
  	2250W/36V	2250W/36V
  	3000W/48V	3000W/48V
  Max. PV open	150V (At minimum operating environment temperature)	200V (At minimum operating environment temperature)
  circuit voltage	138V (At 25℃ environment temperature)	180V (At 25℃ environment temperature)
  MPP Voltage Range	(Battery voltage +2V)～108V①	(Battery voltage +2V)～144V①
  Tracking efficiency	≥98.0%
  Conversion efficiency	≤99.5%
  Temperature compensate coefficient	－3mV/℃/2V (Default)
  Self-consumption	98mA/12V;60mA/24V;50mA/36V;46mA/48V
  Grounding	Common negative
  RS485 interface	RS485(RJ45)
  LCD backlight time	60S (Default)





  ① The Max. PV open circuit voltage must never exceed 138V or 180V at 25℃ environment temperature.

Environmental Parameters:

Mechanical Parameters:

• Item	Tracer6415/6420AN
  Dimension	340×236×119mm
  Mounting dimension	260×224mm
  Mounting hole size	Φ7
  Terminal	2AWG(35mm2)
  Recommended cable	16mm2/5AWG
  Weight	4.5kg
