RAMPS 1.4 Control Panel 3D Printer Control Board for Arduino Mega Reprap
Description:
·This shield is the central control board of the Arduino MEGA based RepRap 3D printer project. This is a shield module which sits above your Arduino board. This allows your Arduino board when fully connected to operate as a 3D printer.
·This module sits on top of the Arduino unit itself. It is compatible with the Arduino MEGA2560.
Features：
1.It has Cartesian robots and regulations of the extruder .
2.Extended to control other accessories.
3.Heater / MOSFET outputs and three fan thermistor circuit.
4.Integration of additional security 5A and component protection.
5.Control of additional heating bed 11A fuse.
6.Suitable for 5 Pololu stepper driver board.
7.Pololu board pin socket, so they can be easily replaced or removed for future designs.
8.I2C and SPI pins left for future expansion.
9.Hooked into all MOSFET PWM pin versatility.
10.Servo type connector is used to connect to the end stop , the motor and the light-emitting diodes. These connectors are gold-plated , rated current of 3A, very compact.
11.On the SD card to add - is now available from the Kliment - Sdramps.
12.LED indicate when the heater output.
13.Option 2 motors connected to Z Prusa Mendel.
Package Including：
1 x RAMPS 1.4 Control Panel 3D Printer Control Board
