Feature
USB dual meter is small in size
It can display USB charging or discharging voltage and current at the same time and on the same screen, alternately or single display capacity and power
Adopt USB extension cable input, output at both ends, easy to use
The USB double meter adopts exquisite SMT craftsmanship, so the consistency is very good
Built-in intelligent charging identification IC, which can automatically match high current charging
USB dual meter is small in size
It can display USB charging or discharging voltage and current at the same time and on the same screen, alternately or single display capacity and power
Adopt USB extension cable input, output at both ends, easy to use
The USB double meter adopts exquisite SMT craftsmanship, so the consistency is very good
Built-in intelligent charging identification IC, which can automatically match high current charging
Specification
Product name: USB test table
Display mode: 0.28"LED, single color (full red), two colors (red and blue) color optional
Product size: 69×26×19mm
USB extension cable: ≥120mm
Measurement accuracy: 0.1% (±3 digits)
Measurement rate: ≥500mS/time
Working temperature: -10～+65℃
Working air pressure: 80～106kPa
Working humidity: 10～80% (no condensation)
Sun exposure: no direct sunlight
Input voltage Test voltage: 3.20-30.0V (automatic shift of decimal point) Resolution below 10V: 0.01V Resolution above 10V: 0.1V
Test current: 0.00-3.00A (up to 10A, can not work for a long time) Resolution: 0.01A
Automatic identification: OUTPUT Ⅱ has built-in intelligent charging control IC, which can automatically match your mobile phone and tablet with suitable and safe high-current charging
QC2.0 QC3.0: OUTPUTI supports Qualcomm QC2.0, QC3.0 charging (Note, when using QC2.0, QC3.0 charging, OUTPUT II cannot be plugged into other devices)
Capacity test: 0-99999mA/H (ie 99.999A/H)
Capacity accumulation: in the case of uninterrupted power, the accumulation of N times of charging capacity
Capacity view:
1. Power on without connecting any USB device, the displayed capacity is the last accumulated capacity, and the accumulated capacity has a power-off memory function
2. After the power-on capacity is cleared, the displayed capacity is the accumulated capacity of the current N times of charging or discharging.
3. You can switch to view by pressing the button
Clear the capacity:
1. When the power is turned on and recharged after a power failure, the last accumulated capacity "flashes twice" is cleared to zero
2. Long press the button to accumulate capacity and the accumulated capacity will be reset by "flash twice"
Power test: 0.00-9.99-99.9W, the decimal point is automatically shifted
Overvoltage alarm: when the voltage is >/=5.6V, the voltage decimal point - flashes quickly
Undervoltage alarm: when the voltage is </=4.4V, the voltage decimal point - flashes slowly
Overcurrent alarm: when the current >/=3A, the current decimal point - flashes quickly
Short circuit alarm: current decimal point - flash quickly
Button: One button, you can switch 7 different display modes: only VA, only C, and only P—VA+C—VA+P—C+P—VA+C+P, long press the button to clear the accumulated capacity alarm When prompted, you can long press the button to cancel the alarm prompt function
Product name: USB test table
Display mode: 0.28"LED, single color (full red), two colors (red and blue) color optional
Product size: 69×26×19mm
USB extension cable: ≥120mm
Measurement accuracy: 0.1% (±3 digits)
Measurement rate: ≥500mS/time
Working temperature: -10～+65℃
Working air pressure: 80～106kPa
Working humidity: 10～80% (no condensation)
Sun exposure: no direct sunlight
Input voltage Test voltage: 3.20-30.0V (automatic shift of decimal point) Resolution below 10V: 0.01V Resolution above 10V: 0.1V
Test current: 0.00-3.00A (up to 10A, can not work for a long time) Resolution: 0.01A
Automatic identification: OUTPUT Ⅱ has built-in intelligent charging control IC, which can automatically match your mobile phone and tablet with suitable and safe high-current charging
QC2.0 QC3.0: OUTPUTI supports Qualcomm QC2.0, QC3.0 charging (Note, when using QC2.0, QC3.0 charging, OUTPUT II cannot be plugged into other devices)
Capacity test: 0-99999mA/H (ie 99.999A/H)
Capacity accumulation: in the case of uninterrupted power, the accumulation of N times of charging capacity
Capacity view:
1. Power on without connecting any USB device, the displayed capacity is the last accumulated capacity, and the accumulated capacity has a power-off memory function
2. After the power-on capacity is cleared, the displayed capacity is the accumulated capacity of the current N times of charging or discharging.
3. You can switch to view by pressing the button
Clear the capacity:
1. When the power is turned on and recharged after a power failure, the last accumulated capacity "flashes twice" is cleared to zero
2. Long press the button to accumulate capacity and the accumulated capacity will be reset by "flash twice"
Power test: 0.00-9.99-99.9W, the decimal point is automatically shifted
Overvoltage alarm: when the voltage is >/=5.6V, the voltage decimal point - flashes quickly
Undervoltage alarm: when the voltage is </=4.4V, the voltage decimal point - flashes slowly
Overcurrent alarm: when the current >/=3A, the current decimal point - flashes quickly
Short circuit alarm: current decimal point - flash quickly
Button: One button, you can switch 7 different display modes: only VA, only C, and only P—VA+C—VA+P—C+P—VA+C+P, long press the button to clear the accumulated capacity alarm When prompted, you can long press the button to cancel the alarm prompt function
List
1 x USB Tester
1 x USB Tester
