Product Type: Alternator |
Replaces: RE509106 AR186125 0-986-040-290 0986040290 3E7285 3911248 3920679 |
  • Amperage: 65 |
  • Fan: External |
  • Grooves: 5 |

12V 65A Alternator Case 1835B 1840 1845C W11B 390 Diesel Cummins 3920679 IA0595

Replaces Part Numbers & Specifications

OEM PART NUMBERS:
• Service Europe: 0986040290 / 0-986-040-290
• Case: AR186125
• 3E7285
• Cummins: 3911248 / 3920679
• Hella: 8EL737217001 / 8EL-737-217-001
• John Deere: RE509106
• Letrika (Iskra): 11201935 / IA0595 / IA0998 / AAK3330 / AAK5123

SPECIFICATIONS:
• Voltage: 12V
• Amperage: 65A
• Fan: External
• Regulator: Internal
• Grooves: 5
• Shaft OD: 0.669in / 17mm
• Shaft Threads: M16-1.5
• Mounting Ear 1: M8-1.25 Threaded
• Mounting Ear 2: 10.5mm Unthreaded
• Mounting Ear 1 Thickness: 0.65in / 16.5mm
• Mounting Ear 2 Thickness: 2.008in / 51mm
• Mount Type: Spool
• B+ Terminal: M6-1.0
• D+ Terminal: Spade
• W Terminal: Spade
• Weight: 10.54 lbs / 4.79 kg
• Condition: New

APPLICATION:
• Case Uni-Loader 1835B/1835C/1840/1845C (1982-1999)
• Case Lift Truck 584E/585E/586E 390 Diesel (1990-1992)
• Case Trencher 550/760 (1988-1992) / Wheel Loader W11B (1983-1993)
• John Deere 7405/450H/450G 4045T (1993-1997)
• Raptor Sprayer 850/1000 Pro/1200 Pro (2003)

12V 65A Alternator — Case Equipment / John Deere / Raptor
Direct replacement -type 12V 65A alternator for Case uni-loaders, lift trucks, trenchers (1982-1999), John Deere tractors/crawlers, and Raptor sprayers. Spool mount with 5-groove pulley. Replaces 0986040290, Case AR186125, Cat 3E7285, Cummins 3911248/3920679, Hella 8EL737217001, JD RE509106, Letrika 11201935.

Product Notice

As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

CASE LIFT TRUCKS:
• 584E / 585E / 586E 390 Diesel (1990-1992)

CASE TRENCHERS:
• 550 4-390 Diesel (1989-1991)
• 760 390 Diesel (1988-1992)

CASE UNI-LOADERS:
• 1835B 148/159 Gas / 188 Diesel (1982-1988)
• 1835C Teledyne Diesel / Gas Engines (1987-1991)
• 1840 390 Diesel (1990-1999)
• 1845C 390 Diesel (1987-1992)

CASE WHEEL LOADERS:
• W11B 390 Diesel (1983-1993)

JOHN DEERE EQUIPMENT:
• 7405 Agricultural Tractor (1997)
• 450H Crawler 4045T (1993)
• 450G Industrial Tractor 4045T (1993)

RAPTOR SPRAYERS:
• 850 (2003)
• 1000 Pro (2003)
• 1200 Pro (2003)

NOTE: Verify OEM part number from your original unit before ordering to ensure proper fitment.
