Product Type: Starter |
Replaces: 0R9226 0R9226 1454651 |
  • Starter Type: OSGR |
  • Volts: 12 |
  • Teeth On Drive: 10 |
  • Rotation: Clockwise |
  • Kw: 4 |
  • Source: Aftermarket

12V OSGR Starter 2000-2003 Ford F650 F750 Super-Duty Cat 3126 228000-5850

Replaces Part Numbers & Specifications

OEM PART NUMBERS:
• Caterpillar: 0R9226
• Denso: 228000-5850, 228000-5851, TG228000-5851
• Denso: 280-8019, 9722809-585
• Bluebird: 1454651, 1935485
• Navistar: 2585347C91

SPECIFICATIONS:
• Voltage: 12V
• Type: OSGR (Off Set Gear Reduction)
• Power: 4 kW / 5.36 HP
• Rotation: CW (Clockwise)
• Tooth Count: 10
• Gear OD: 38.7mm / 1.524in
• Mounting Ear 1: 10.0mm ID Unthreaded
• Mounting Ear 2: 10.0mm ID Unthreaded
• Weight: 26.12 lbs / 11.87 kg
• Condition: New

APPLICATION:
• Bluebird Bus Cat 3116/3126 (1996-2003)
• Ford F600/F700/F800/F900 Cummins 8.3L-504 (1992-1999)
• Ford F650/F750 Super-Duty Cat 3126 (2000-2003)
• Ford L6000/L7000/L8000/L9000 Cat 3126/Cummins 8.3L (1992-1999)
• Kenworth T300 Cummins 5.9L ISB (2004-2007)

12V OSGR Starter — Ford F650 F750 Super-Duty Cat 3126 7.2L
Off set gear reduction starter motor designed for the Ford F650 and F750 Super-Duty trucks with Caterpillar 3126 7.2L 441cid diesel engines from 2000-2003. This 12-volt unit produces 4 kW of cranking power through a 10-tooth pinion gear with clockwise rotation. The OSGR design delivers higher cranking torque with lower current draw compared to direct drive starters. Features 10.0mm unthreaded mounting ears for direct bolt-on replacement. Also compatible with Bluebird bus Cat 3116/3126 applications and Ford F600-F900 with Cummins 8.3L. Replaces Denso 228000-5850, Caterpillar 0R9226.

Product Notice

As a parts distributor we mostly sell aftermarket parts (any OEM parts would be noted as such). Aftermarket parts are not sourced from the original vehicle or equipment manufacturer, but are designed to function the same as - if not better than - the original. All parts sold are new.

BLUEBIRD BUS:
• All Models Caterpillar 3116 (1996-2003)
• All Models Caterpillar 3126 (1996-2003)

FORD MEDIUM/HEAVY DUTY TRUCKS:
• F600/F700/F800/F900 Cummins 8.3L-504 FD1460 (1992-1999)
• F650 Super-Duty Caterpillar 3126 7.2L 441cid (2000-2003)
• F750 Super-Duty Caterpillar 3126 7.2L 441cid (2000-2003)
• L6000/L7000/L8000/L9000 Caterpillar 3126 (1998-1999)
• L6000/L7000/L8000/L9000 Cummins 8.3L-504 FD1460 (1992-1999)

KENWORTH:
• T300 Medium Duty Cummins 5.9L ISB 359cid (2004-2007)

NOTE: Verify OEM part number before ordering to ensure proper fitment.
