Fits John Deere Secondary Fuel Filter - DZ112918

DESCRIPTION


One New Aftermarket Replacement Secondary Spin-On Fuel Filter for John Deere Tractors, Combines, Harvesters, and More

This aftermarket replacement secondary spin-on fuel filter fits a wide range of John Deere (JD) equipment powered by FT4/IT4 and PowerTech engines. Installed downstream of the primary filter, it provides final-stage filtration to protect fuel injectors and fuel pumps from fine contaminants and water. The filter features coated filtration media that traps and repels water to help prevent rust, microbial growth, and fuel system damage. It includes an integral post seal and uses a standard spin-on design for quick, tool-friendly replacement. Replaces OEM part numbers RE533910 and RE533911, with DZ112918 being the current superseding John Deere part number.

Specifications

  • Type: Secondary / Final Spin-On Fuel Filter
  • Length: 9-1/4"
  • Outer Diameter: 4-11/32"
  • Thread Size: 1-14
  • Contains: Integral Post Seal

Compatible Models

John Deere R-Series Tractors: 6135, 6175R, 6195R, 6215R, 7210R, 7230R, 7250R, 7260R, 7270R, 7280R, 7290R, 7310R, 7R 290, 7R 310, 7R 330, 7R 350, 8235R, 8245R, 8260R, 8270R, 8285R, 8295R, 8310R, 8320R, 8335R, 8345R, 8360R, 8370R, 8400R, 8R 230, 8R 250, 8R 280, 8R 310, 8R 340, 8R 370, 8R 410, 9330, 9360R, 9370R, 9410R, 9420R, 9430, 9460R, 9470R, 9510R, 9520R, 9530, 9560R, 9570R, 9600, 9630

John Deere RT/RX/RX Tracked Tractors: 8310RT, 8320RT, 8345RT, 8360RT, 8370RT, 8RT 310, 8RT 340, 8RT 370, 8RT 410, 8RX 310, 8RX 340, 8RX 370, 9420RX, 9430T, 9460RT, 9470RT, 9470RX, 9510RT, 9520RT, 9520RX, 9530T, 9560RT, 9570RT, 9570RX, 9630T

John Deere S/STS Combines: S650, S650 STS, S660, S660 STS, S670, S670 STS, S680, S680 HM, S680 STS, S685, S685 HM, S685 STS, S690, S690 HM, S690 STS, S760, S770, S780, S785, S790, STS14, STS16, CH570, CH670, CS690, CP690, CP770, T550, T560, T660, T670, W235, W260, W540, W550, W650, W660

John Deere Forage Harvesters: 7280, 7350, 7380, 7450, 7480, 7550, 7580, 7750, 7780, 8100, 8200, 8300, 8400, 8500, 8600, 8800, 9600

John Deere Cotton Pickers/Strippers: 7760, CP690, CP770, CS690, R4030, R4038, R4040I, R4044, R4045, R4060, 2854, 2654G, 2656G, 4940, F4365

John Deere Sprayers: R4030, R4038, R4040I, R4044, R4045, R4060

John Deere Graders: 620G, 622G, 670G, 672G, 770G, 772G, 870G, 872G

John Deere Wheel Loaders: 524P, 624K, 624K-II, 624L, 624P, 644G, 644K, 724K, 724L, 724P, 744K, 744L, 824K, 824L, 844K, 844K-III, 844L, 844LAH, 850K, 850L, 850L PL, 944K, 950K, 1050K, 1050K PL

John Deere Skidders: 640L, 643L, 643L-II, 648L, 648L-II, 748L, 748L-II, 844L, 848L, 848L-II, 948L, 948L-II

John Deere Dozers: 750K, 850K, 850L, 850L PL

John Deere Wheeled Feller Bunchers: 643L, 643L-II, 843L, 843L-II

John Deere Tracked Feller Bunchers: 803M, 803MH, 853M, 853MH, 859M, 859MH, 903M, 953M, 953MH, 959M, 959MH

John Deere Log Loaders / Forestry Excavators: 1270E, 1270G, 1470E, 1470G, 1910G, 2654G, 3154G, 3156G, 3754G, 3756G

John Deere Excavators: 250G, 260E, 310E, 370E, 410E, 460E, 460E II, 410E II, 260E, 370E

John Deere Articulated Dump Trucks: 260E, 310E, 370E, 410E, 460E

John Deere Power Units / Engines: 6090H, 6135, PowerTech PSX 9.0L, PowerTech Plus 13.5L, PSS 13.5L, PSX6135

John Deere Sugar Cane Harvesters: 3154G, 3156G, 3754G, 3756G

Replaces Part Number(s):

RE533910, RE533911, DZ112918, AH533910

Aftermarket Interchange Numbers

Baldwin BF9917, Fleetguard FS1093, Pallman SP1340M, S119392

New aftermarket replacement part - not remanufactured, not used.

NEW
6 Month Warranty
