We are an authorised Ortofon dealer, so you can be assured of new and genuine products, covered by a full manufacturers warranty.

The DJ S replacement stylus from Ortofon is for the S cartridge, which is a solid-built cartridge in a blue nylon material. The stylus has a fine spherical stylus and a special developed and extremely balanced cantilever to give you outstanding levels of rigidity.

Not only does the S cartridge have a most sufficient tracking ability, it is also virtually unbreakable and provides the DJs with the most needed stringency. Plus, it equals very low record wear, an advantage for busy DJ's. The DJ series has been known to many as the "jack of all trades," with improved tracking, alongside of accurate sound reproduction. Featuring a low wear stylus design, the DJ provides excellent groove handling, even with less weight applied.


The other styli are listed here

Specifications:
  • Output voltage at 1000Hz, 5cm/sec.  - 6 mV
  • Channel balance at 1kHz  - 2 dB
  • Channel separation at 1kHz  - 23 dB
  • Channel separation at 15 kHz  - 15 dB
  • Frequency range at -3dB  - 20-20.000 Hz
  • Frequency response  - 20-18.000 Hz 3dB/-2dB
  • Tracking ability at 315 Hz at recommmende tracking force  - 80 μm
  • Compliance, dynamic lateral -  9 μm/m N
  • Stylus type  - Spherical
  • Stylus tip radius  -  R 18 μm
  • Tracking force range  - 2.0-4.0 g (20-40 mN)
  • Tracking force recommended -  3.0 g (30 mN)
  • Tracking angle -  20°
  • Internal impedance, DC resistance -  750 Ohm
  • Internal inductance  - 450 mH
  • Recommended load resistance  - 47 kOhm
  • Recommended load capacitance  - 200-600 pF
  • Concorde cartridge weight  - 18.5 g
  • Compatible with cartridges -  DJ S
