Specifications:
High Performance Racing Spec.
2-Row of tubes Core Racing Design
Core and Tank Material:Full Aluminium
Overall Diameter: Height 26 1/2 in X Width 23 1/8 in
Core Diameter: Height 20 in x Width 21 in
Inlet Diameter: 1 3/4 in located on the Center
Outlet Diameter: 1 1/2 in located on the Passenger
Internal Transmission Oil Cooler: No
APPLICATIONS
1949 Plymouth Deluxe Base,
1949 Plymouth Deluxe Base, 20" Tall
Core - Brackets on Grille Side
1949 Plymouth Special Deluxe Base,
1949 Plymouth Special Deluxe Base, 20"
Tall Core - Brackets on Grille Side
1949 Plymouth Suburban Base,
1949 Plymouth Suburban Base, 20" Tall
Core - Brackets on Grille Side
1950 Plymouth Deluxe Base,
1950 Plymouth Deluxe Base, 20" Tall
Core - Brackets on Grille Side
1950 Plymouth Special Deluxe Base,
1950 Plymouth Special Deluxe Base, 20"
Tall Core - Brackets on Grille Side
1950 Plymouth Suburban Base,
1950 Plymouth Suburban Base, 20" Tall
Core - Brackets on Grille Side
Please Notice:
To confirm that this part fits your vehicle, enter your vehicle's Year, Make, Model, Trim and Engine in the Compatibility Table. Also review the notes section in the compatibility chart for additional specifications about this part！！
Description：
Our Radiator is made of AA5052 aircraft aluminum. Its different from other sellers T-3303 Series. In fact, AA5052 series Aluminum is much better than T-3303 series.
More than 90% of aftermarket manufacturers use the T-3303 series Aluminum, because it is cheaper and easier to get the material. However, T-3303 aluminum has many disadvantages, such as poor polishing effect, softness, easiness to scratch and corrode, poor heat dissipation effect. If the T-3303 aluminum radiator is operated in high pressure and high temperature for a long time, the leaking problem would occur very soon.
AA5052 Aluminum is an Al-Mg alloy with good corrosion resistance, excellent reliability and cold work ability and strength. The main alloying element of AA5052 is magnesium, which has good forming and processing properties. It is widely used in the manufacture of aircraft fuel tanks, oil pipes, and sheet metal parts of transportation vehicles and ships, hardware products, and electrical-appliance casings.
This AA5052 Aluminum Radiator is designed to provide maximum cooling efficiency to prevent premature engine failure. Its light-weight, and high-heat transferring aluminum features a tube and fin design that, dramatically increases surface area that enables the heat to dissipate more efficiently. This AA5052 Aluminum Radiator is at least 30%-45% more efficient than stock ones. Most importantly, it has a much higher capacity for coolant than stock ones, which means that your cooling system will be more efficient and will be more resistant to temperature surges in racing applications.
· Made from Aircraft AA5052 grade aluminum for prolonged lifespan and with raw aluminum finish
· Brazed core technology to guarantee optimum performance and dependability
· All AA5052 Aluminum 2mm thick tanks and fittings,Ensure it's hard and durable
· Billet Aluminum CNC machined fill neck rugged and durable
· CNC machined cap with Engraved craftsmanship, anodized treatment.
· OEM style brass petcock drain much better than other plastic one on eBay
· Carefully crafted to exceptional OE standards for precise fit.
Alloyworks Radiators has carved a niche by addressing commoninstallation pain points, Their radiators are designed with two keyprinciples:
Precision Fitment
Alloyworks
radiators are built to match factory dimensions,ensuringcompatibility
with stock fans, shrouds, and mounting points. Thiseliminates the need
for cutting or welding in most cases.
High Performance Materials
Constructed
from lightweight, corrosion resistant aluminum, theseradiators feature
advanced cooling fin designs for improved heatdissipation ideal for high
stress applications like racing or towing.
Plug and Play Compatibility
Many
models include pre installed bungs for sensors and pre drilled holesfor
OEM style fittings, reducing the need for adapters or custom parts.
Customer Support
Alloxwgrks
provides detailed installation guides and responsive supportto
troubleshoot fitment issues, a rarity in the aftermarket space.
