4+2 Port Gigabit PoE Switch
Ten Times Faster.
Four Gigabit PoE ports · Two Gigabit uplinks · Digital power display · DIP mode switch · 250m Extend
Every feature, at a glance
A visual tour of what's inside -- before we break it all down, tile by tile.
Switch features at a glance
Every UKVISION switch is engineered to the same exacting standard -- thermal management, fault protection, industrial-grade components and a premium metal housing built for years of 24/7 service.
Built from the inside out
Every specification on this switch exists for one reason -- to make your CCTV or network install faster, cleaner, and more reliable.
Engineered, annotated, accounted for
An honest engineering breakdown of the UK-SW-4-1000-P. Everything is where it needs to be -- and nothing is where it shouldn't.
UKVISION Identity
Silkscreen brand panel -- British design, tested UK stock.
4 × PoE Ports
10/100/1000Mbps Gigabit, 30W each, IEEE 802.3af/at, auto MDI/MDIX.
2 × Uplink Ports
Non-PoE Gigabit uplinks for NVR / router connection. Ports 5–6 at 10/100/1000Mbps.
AC Power Input
100–240V universal input. Ships with UK 3-pin BS1363 cable fitted.
Metal Chassis · 11" / 1U
Compact desktop form factor. Convection cooled. Fanless. Industrial-grade housing.
65W of headroom, mapped out
A typical HD IP camera draws 6–8W. With 65W on tap across 4 PoE ports, this switch comfortably powers a full 4-camera HD install with plenty of headroom for accessories like PTZs and IR illuminators.
32W used / 65W available
Built for both worlds
Whether it's your first home CCTV kit or your 200th site install this year -- this was specified for you.
Plug in. Power up. Done.
- No configuration -- works out of the box
- Powers up to 4 HD IP cameras from one compact unit
- Genuine UK 3-pin plug (BS1363) fitted
- Premium metal chassis -- fits any shelf, cupboard or utility space
- Works with Hikvision, Dahua, Reolink, Swann & all ONVIF cameras
- UK warranty, UK-based support team
Specified. Stocked. Shipped.
- Compact 200×133mm metal chassis -- desktop or wall-mount
- 802.3af/at with per-port PD auto-detection & protection
- 65W runs 4 HD cameras comfortably -- ideal for small-site deployments
- DIP mode switch -- Switch / VLAN / Extend selectable, no CLI
- VAT invoice included on every order -- reclaim the 20%
- Trade pricing on 5+ units -- message us for a quote
Full technical specifications
Everything needed to confirm compatibility and plan your install.
| Ports & Interface | |
| PoE Downlink Ports | 1–4: 10/100/1000Mbps Gigabit RJ45 PoE Ports |
| Uplink Ports | 5–6: 10/100/1000Mbps Gigabit RJ45 (non-PoE) |
| Total Ports | 6 (4 PoE + 2 Uplink) |
| Auto-Negotiation | Yes -- all ports |
| Auto-MDI / MDI-X | Yes -- all ports |
| PoE Power Supply | |
| PoE Standard | IEEE 802.3af / IEEE 802.3at |
| Max PoE Output per Port | 30W |
| Total PoE Power Budget | 65W |
| DIP Mode Switch | |
| Switch Mode | Standard operation -- all ports communicate with each other |
| VLAN Mode | Ports 1–4 isolated from each other; only communicate with uplinks 5–6 (ideal for CCTV) |
| Extend Mode | Ports 1–4 forced to 10Mbps; transmission distance up to 250m over good-quality cable |
| Performance Specification | |
| Switching Capacity | 12 Gbps |
| Packet Forwarding Rate | 8.928 Mpps |
| MAC Address Table | 2K |
| Processing Type | Store-and-Forward · IEEE 802.3x full-duplex flow control |
| Indicators & Display | |
| Digital Power Display | 3-digit LED display -- total PoE power consumption in real time |
| Power Indicator | ON = power normal · OFF = no power / abnormal |
| Link / Act (Ports 1–6) | ON = connected · Flashing = data transmission |
| Network Standards | |
| Ethernet | IEEE 802.3i 10BASE-T · IEEE 802.3u 100BASE-TX · IEEE 802.3ab 1000BASE-T (Gigabit) |
| Flow Control | IEEE 802.3x full-duplex Flow Control |
| Power over Ethernet | IEEE 802.3af / IEEE 802.3at |
| Energy Efficiency | IEEE 802.3az EEE |
| Physical & Environmental | |
| Dimensions | 200 mm (L) × 133 mm (W) × 44 mm (H) |
| Cabling | UTP Category 5 or higher |
| Power Input | AC 100–240V, 50/60Hz -- UK 3-pin cable included |
| Operating Temperature | 0°C to 45°C |
| Operating Humidity | 10% – 90% non-condensing |
| Storage Temperature | −20°C to 70°C |
| Storage Humidity | 5% – 95% non-condensing |
| Compliance | |
| Certifications | CE · UKCA · RoHS |
| Camera Protocols | Fully ONVIF-compatible (Profile S / T / G IP cameras) |
Dimensions & physical footprint
Compact, metal-housed and engineered to fit neatly on any shelf, cupboard or desk. Here's exactly how much space the switch needs.
Open it. Use it.
Everything needed to power up and get connected -- exactly what the manual lists, nothing missing, nothing padded.
Frequently asked questions
From the UKVISION tech team -- no corporate fluff. Tap any question to reveal the answer.
Q.Will this switch power my Hikvision, Dahua, Reolink or Swann cameras?
Yes. The switch is fully IEEE 802.3af/at compliant, covering virtually every PoE IP camera sold in the UK -- Hikvision, HiLook, Dahua, Reolink, Swann, Uniview, Ubiquiti, Axis, Hanwha. If your camera supports standard PoE or PoE+, it will work.
Q.Does it need any configuration?
No. This is a plug-and-play unmanaged switch. Connect your cameras to PoE ports 1–4 and your NVR or router to one of the two uplink ports (5–6) -- it's working in seconds. No apps, passwords or CLI.
Q.What's the difference between PoE and PoE+?
Standard PoE (802.3af) delivers up to 15.4W per port; PoE+ (802.3at) delivers up to 30W. This switch supports both, so it runs lower-power devices and high-draw cameras like PTZs and 4K turrets with zero compatibility issues.
Q.Can I connect non-PoE devices to the PoE ports?
Yes. The switch auto-detects each connected device. Power is only delivered to PoE-enabled hardware -- non-PoE devices receive a data-only connection, exactly as on any standard network switch.
Q.How far can I run a camera from the switch?
Up to 100 metres on a standard Gigabit link, at full 1000Mbps speed. Using the DIP switch to engage Extend mode, ports 1–4 are forced to 10Mbps which extends transmission distance to 250 metres -- ideal for outbuildings, gates and far perimeters without fibre.
Q.Will it power all 4 cameras at once?
Yes, comfortably. A typical HD IP camera draws 6–8W. With 65W across 4 PoE ports, you have clear headroom for a full 4-camera install -- even 4 full-power 4K cameras at 10W each only use 40W, leaving 25W for PTZs, IR illuminators and other accessories.
Q.Can I daisy-chain two switches together?
Yes. Use either of the two Gigabit uplink ports (5–6) to connect to a second switch, router or core aggregator. Each copper link supports up to 100m per run at full Gigabit speed.
Q.Where can I install this switch?
Anywhere clean, dry and well-ventilated. The compact 200×133×44mm premium metal chassis sits neatly on a desk, shelf or in a cupboard. Keep 10cm of free space around it for heat dissipation.
