PVS31 AEGIS-31 Gen.4 — Digital Night Vision Device (0.39 Pro)

🔹 Product Overview

The PVS31 digital night vision device of the 4th generation in the Pro Version offers several improvements over the standard version: independent power supply, brightness control, switching between green and white phosphor, and a highly integrated control switch for a compact, robust user experience.

The night vision device uses a special Sharp Core sensor, offers a battery life of approx. 4.5 hours, a frame rate of 50, a latency of 20 milliseconds and a 0.39 inch Sony OLED screen. Field of view: 40 degrees, square field of view.

📐 Technical Specifications

🌟 Key Features

• 💡 Brightness control — Pro version allows finer adjustment to different light conditions.
• 🌈 Colour switching — Switchable between green and white phosphor (depending on preference and scene).
• 🔌 Independent power supply — Type-C charging port; no additional chargers required.
• 🛡️ Robust design — No visible modifications to the housing, splash-proof for everyday use, robust for outdoor applications.

❓ Frequently Asked Questions

🔧 PVS31 — Pro vs Standard (Differences & Highlights)

PVS31 Digital Night Vision Device Gen.4 0.39 Pro — Upgrade

【New compared to the standard version】

1. Independent housing power supply
2. Brightness control function
3. Switching between green and white phosphor display
4. Highly integrated control switch

【Device highlights】

1. Highly integrated switch: The Pro model has been revised based on the FMA model. Unlike the standard three-stage switch, the Pro version uses a single highly integrated switch that controls all functions: On/Off, IR illumination, colour switching and brightness control. The external appearance and battery cover remain undamaged — no additional drilling is required. The battery pack is conveniently charged via a modern Type-C port, so you don’t need a separate charging adapter when travelling.
2. Robust, integrated design: The internal wiring is routed inside the housing without removing critical axles (no weakening of the housing structure). Protection class: splash-proof for everyday use. The device also features a true 18× optical eyepiece (not cheap acrylic), dioptre adjustable and therefore suitable for glasses wearers. Objective and eyepiece are removable for easy cleaning and maintenance.

Battery difference

The Standard Version uses an external battery box as its default power source. The Pro Version can be operated both with an external battery box and independently with a single 14500 (3.7V) pointed cell directly in the housing.

⚠️ Notes / Safety

• When charging the battery pack, ideally avoid fast smartphone chargers, as excessive power may damage the battery.
• For independent housing power supply, a single 14500 (3.7V) pointed cell is required — insert it with the positive pole facing outwards. Caution: never insert incorrectly. If the battery casing is damaged, remove the battery from use immediately.
• A blue screen or vertical stripes indicate low battery — not necessarily a defect; please recharge in time.
• Switch off IR illumination when idle to avoid overheating or damage.
• Use only the supplied battery box or approved battery types for power supply — do not use foreign power sources.

📦 Scope of Delivery
