SPECIFICATIONS: SWING OVER BED ........................ 14" SWING OVER CROSS SLIDE ................ 6.7" HEIGHT OF CENTER ...................... 6.8" DISTANCE BETWEEN CENTERS .............. 40" CROSS SLIDE WIDTH ..................... 6.625” BED WIDTH & DEPTH ..................... 8.5" x 10" SPINDLE NOSE CAMLOCK .................. D1-4 SPINDLE BORE .......................... 1.5" SPINDLE SPEEDS INFINITELY VARIABLE 3 RANGES - LOW RANGE ......................... 30 - 140 RPM - MEDIUM RANGE ...................... 110 - 540 RPM - HIGH RANGE ........................ 410 - 2000 RPM SPINDLE TAPER ......................... #5MT SPINDLE MOTOR ......................... 5 HP MIN SPINDLE SPEED FOR FULL POWER ...... 70 RPM AXES X-AXIS RAPID TRAVERSE ............ 100 IPM Z-AXIS RAPID TRAVERSE ................. 100 IPM X, Z SERVO MOTOR ...................... 1.6 HP TAILSTOCK TAILSTOCK QUILL DIAMETER .... 1.75" TAILSTOCK QUILL TAPER ................. 3MT TAILSTOCK QUILL STROKE ................ 4.75" FLOOR DIMENSIONS ...................... 81.5" X 53.5" X 66.3" APPROXIMATE MACHINE WEIGHT ............ 2,750 LBS. ACU-RITE TURN POWER CONTROL THE TURNPWR IS A CONTOURING CONTROL THAT ENABLES YOU TO PROGRAM CONVENTIONAL MACHINING OPERATIONS RIGHT AT THE MACHINE IN AN EASY-TO-USE CONVERSATIONAL LANGUAGE. 12.1” COLOR LED DISPLAY, 1.4 GHZ DUAL CORE CELERON PROCESSOR, 2.5GB CFAST (SATS) USER INTERNAL STORAGE. DRO MODE • MULTIPLE DATUMS (FIXTURE OFFSET):99 • ZERO RESET • NEAR ZERO WARNING PGM MODE • THREAD CYCLES, RECESS CYCLES, TURNING CYCLES • POSITION/DRILL, LINE, ARC, BLEND (BLEND/CHAMFER) • ESTIMATED MACHINING TIME • VIEW GRAPHICS: 2DLINE / 3D LINE /3D SOLID • BLOCK FORM W/USER OVERIDE • REPLICATION (REPEAT) • COMMENT STEP – EVENT COMMENTS • PROGRAM MANAGER NAVIGATION TREE W/PROGRAM TYPE FILTER • LONG PROGRAM NAMES • PROGRAM PREVIEW: LISTING AND GRAPHIC W/ESTIMATED MACHINE TIME • EXPLODE STEP: REPEAT • REVERSE (STEP / PATH) • SHIFT STEPS • AUTO SAVE (PROGRAM) • PROGRAM SIZE LIMIT (TPT ONLY):9999 STEPS • DXF FILE IMPORT • G-CODE PROGRAM: W/GRAPHICS SUPPORT / SIMPLE EDIT • ON SCREEN HELP: USER MANUAL VIEWER (TEXT AND GRAPHICS) • PARTS COUNTER AND CLOCK • OPTIONAL STOP (G-CODE ONLY) • FEED OVERRIDE BY POTENTIOMETER • ERROR COMPENSATION: LINEAR AND BIDIRECTIONAL NON-LINEAR • COMMUNICATION PORTS – (2) USB AND ETHERNET * COOLANT SYSTEM * 3-JAW CHUCK * ALORIS QUICK CHANGE TOOLPOST w/HOLDERS * 5 HORSE POWER SPINDLE MOTOR Voltage: 230 INSPECT UNDER POWER IN OUR WAREHOUSE CONDITION: **** LIKE NEW ****
