Note: The Handpiece Lubricator must be connected to the air compressor
Handpieces show in the photos are not included, only for display.
Features:
Can be maintained for 2pcs high speeds and 1pcs low speed at the same time
Can be maintained for all brands.
With the ability to precisely control the time of oiling
With “AIR ” key, after the oiling cleaning is finished, you can get out of the excess oil in the handpiece.
The door cover is used to effectively reduce the oil mist diffusion and ensure a clean working environment.
Intelligent working mode, no need to set the filling time every time.
When the machine is running, there is no abnormal noise, and the noise is not greater than 60DB.
Specifications:
1.Rated voltage: AC110V±11V,60HZ±10HZ
2.Rrated power:40W
3.Air pressure:4KG/ cm2 —8kg/cm2
4.Work pressure:3KG/ cm2 —3.5kg/cm2
5.Tank capacity:300ml
6.Motor parameters: A:Rated voltage :12V(DC) B:Rrated power:6W C:speed:3000rmp/min
7.Working temperature:5-40°C
8.Net weight: 7.2KG
9.Size: 300*230*360mm
10.Packing size:335*260*400mm
Packing List:
(1)Oil lubricator (1 PCS)
(2)Using Instructions (1 PCS)
(3)Sewage pipe (1 PCS)
(4)Funnel (1 PCS)
(5)Fuse(1 PCS)
(6)Seal ring(4 PCS)
(7)Quick connector(3 PCS)
