Alloy Carbon Road Wheels Ainekasports ANSLWAC24-80
SPECS
Rim material: Toray full carbon fiber with Alloy braking surface
Rim type: Clincher
Surface Weave: 3K/UD, Matte/Glossy
Rim height: 24mm,38mm, 50mm, 60mm, 80mm
Rim width: 20.5mm/23mm
Rim holes: Front 20H, Rear 24H
About rim weight: 24mm height 20.5mm wide Clincher: 480g(+/-15g)
38mm height 20.5mm wide Clincher: 550g(+/-15g)
38mm height 23mm wide Clincher: 575g(+/-15g)
38mm height 25mm wide Clincher: 595g(+/-15g)
50mm height 20.5mm wide Clincher: 590g(+/-15g)
50mm height 23mm wide Clincher: 645g(+/-15g)
50mm height 23mm wide Clincher: 645g(+/-15g)
60mm height 20.5mm wide Clincher: 650g(+/-15g)
60mm height 23mm wide Clincher: 740g(+/-15g)
60mm height 25mm wide Clincher: 740g(+/-15g)
80mm height 20.5mm wide Clincher: 790g(+/-15g)
80mm height 23mm wide Clincher: 820g(+/-15g)
80mm height 25mm wide Clincher: 820g(+/-15g)
Rims weight note:
The weight is just a reference weight, not the absolute weight, due to continuous improvement and updating of technology, the actual weight will be biased.
HUBS
Specification: Novatec A291SB-SL/F482SB-SL
Weight: Front 60g, Rear 228g
Rolling System: Sealed Bearing: Front 2 Rear 4
Spoke Holes: Front 20H, Rear 24H
O.L.D: Front 100mm, Rear 130mm
Color: Black, Red or White
Pawls: 3 pawls
Free Hub Body: Shimanoo system 9/10/11 speed or Campag system 9/10/11 speed.
Spokes: Aero spokes, made in Taiwan.
Nipples: Alloy nipples in red/black, made in Taiwan.
ORDER NOTE
After your order, please choose from the following order specs template and send back to us.
Appearance: 3K or UD
Finishing: Matte or Glossy
Hubs color: Black, Red or White
Hub compatibility: Shimanoo 9/10/11 Speed or Campag 9/10/11 Speed
Spokes color: Black or White
Nipples color: Black, Red or Silver
Skewer color: Black or Red
If you not leave any massage about the order, we will send 3k matte with all black parts, SHIMAN0 cassette body.
The picture is for reference only, subject to the actual product.
