Product Description
Fitment:
Universal for 12V Motorcycles / Scooter / Motorbike etc.
Note: This is a Mechanical Speedometer, not an Electronic Speedometer.
Specification:
Condition: 100% Brand new
Shell Color: Black
Working Voltage: DC 12V
Material: Metal Housing and Backlight LCD Digital Screen
4 Function: Speedometer / Tachometer / Odometer / Fuel Gauge
Feature:
High cost performance 4-in-1 multifunction motorcycle meter.
Anti-UV & anti-glare LCD screen, direct indication for monitor convenience.
7 different backlight colors free to switch, with self-check function.
Durable Metal shell with sealing design, waterproof, dustproof and long life performance.
Wire Connection:
Black wire for positive 12V
Green wire for negative 12V
White and Blue wire for oil fuel gauge display
Black and Red wire for tachometer display
Package Includes:
1x Motorcycle Speedometer
Setting Guide:
1. Light Color Switch:
7 Colors LED, press the button 3 seconds in ODO mode.
2. KM/H and MPH Switch:
(1) Keep pressing the button, then turn on the power, the screen will display "P0000".
This means you have successfully entered setting mode.
(2) Long press is used to switch the digits, short click is used to change the digits.
Edit the code to "P6610" and the screen displays "00466" to indicate success.
(3) Short click the button to continue, screen displays "1-001", which means KM/H setting.
You can long press the button to enter edit mode.
(4)With short click, change it to "1-002", which means MPH. Long press it to exit the editing mode.
3. Number of Cylinders Setting:
(1) Steps connect to above, short click until the screen displays "2-002", means 2 cylinders.
(2) Enter the edit mode(long press the button), edit the code(short click) to "2-004" means 4 cylinders.
(3) Long press the button to exit the editing mode.
4. Fuel Gauge Setting:
(1) Steps connect to above, short click until the screen displays "3-002", indicating 2-wire oil meter.
(2) Enter edit mode(Long press the button), edit the code(short click) to "3-003", indicating 3-wire oil meter.
(3) Long press the button to exit the editing mode.
(4) Short click to continue the operation and finish.
