Egasky LPDA 4G 5G Directional Antenna – Outdoor Signal Booster for Telstra, Optus, Vodafone, WiFi & LoRa (Australia)

The Egasky LPDA 4G/5G Directional Antenna is a high-performance solution for improving mobile and wireless connectivity across Australia. It covers all major GSM, UMTS, LTE, 3G, 4G, and most 5G bands (excluding mmWave), and is compatible with Telstra, Optus, and Vodafone networks. Suitable for WiFi routers, signal boosters, and LoRa IoT 915MHz applications. Also used for RFID UHF systems (865–868 MHz EU / 902–928 MHz North America / 920–926 MHz Australia), railway telemetry, and remote monitoring.

8/9/9dBi Directional LPDA Outdoor Antenna N Female Supports 5G 4G LTE Wireless WiFi 868mhz RFID for Cellular CPE Router RAK Nebra Bobcat HNT Helium Hotspot Miner SyncroBit LoraWan Gateway

Gain: 8.5 / 9 / 9 dBi

Frequency Range: 698 - 960 & 1710 - 2675 & 3300 - 3700 MHz

Connector: N Female

Dimensions: 300 × 200 × 50 mm

The Egasky EGLPDA-0637-D8/9/9 is a wide-band log-periodic directional antenna covering major GSM, UMTS, LTE, 3G, 4G, and 5G bands across Australia. It supports WiFi, LoRa IoT, and RFID systems — reducing the need for multiple antennas.

Key Features

  • Wide Frequency Coverage: 698-960 MHz / 1710-2675 MHz / 3300-3700 MHz
  • Supports AU Carriers: Optus, Telstra, Virgin Mobile, Vodafone
  • Outdoor Ready: Suitable for rooftops, poles, telemetry units, homes, and offices
  • Lightweight & Easy to Install: Low load on mounts and simple assembly

Applications

  • Cellular CPE Routers: Improve mobile broadband reception
  • LoRaWAN Gateways & IoT Devices: Reliable links for remote sensors
  • RFID Systems: Supports UHF 865-868 MHz (EU) / 902-928 MHz (US) / 920–926 MHz (AU)
  • WiFi Boosters: Works with modems, hotspots and amplifiers

Performance Notes

Two antennas can roughly double throughput (~×1.5–1.8). A single antenna works for routers with one port — connect to the main port. This antenna amplifies received signal but does not create coverage where none exists.

Available Variations

We provide the following 13 variants to suit different installations. Lengths show imperial then metric (≈ rounded):

  1. Only Antenna
  2. Antenna + 10ft (≈3m) RF cable N Female → SMA Male — LMR200
  3. Antenna + 16ft (≈5m) RF cable N Female → SMA Male — LMR200
  4. Antenna + 33ft (≈10m) RF cable N Female → SMA Male — LMR240
  5. Antenna + 10ft (≈3m) RF cable N Female → RP-SMA Male — LMR200
  6. Antenna + 16ft (≈5m) RF cable N Female → RP-SMA Male — LMR200
  7. Antenna + 33ft (≈10m) RF cable N Female → RP-SMA Male — LMR240
  8. Antenna + 10ft (≈3m) RF cable N Female → TS9 — LMR200
  9. Antenna + 16ft (≈5m) RF cable N Female → TS9 — LMR200
  10. Antenna + 33ft (≈10m) RF cable N Female → TS9 — LMR240
  11. Antenna + 10ft (≈3m) RF cable N Female → CRC9 — LMR200
  12. Antenna + 16ft (≈5m) RF cable N Female → CRC9 — LMR200
  13. Antenna + 33ft (≈10m) RF cable N Female → CRC9 — LMR240

Except for variant 1 (Only Antenna), each cable variation includes: 1 × RF coaxial cable, 2 × cable ties, 1 × adapter connector (adapter depends on the selected variant).

These accessories assist a smooth outdoor connection and make the antenna compatible with 5G/4G/LTE modems, MiFi hotspots, routers, cellular signal boosters/amplifiers, LoRaWAN gateways, IoT end-nodes and RFID UHF readers.

Need a 5G modem? We also have easy-to-use USB 5G modems available.
Egasky 5G USB Modem

* View Product

Cable Upgrades — LMR200 & LMR240

To reduce signal loss and improve durability we use low-loss coaxials:

  • LMR200 (used for 3m / 5m cable options): double-layer aluminium foil + tinned copper braid for excellent shielding and flexibility — ideal for short runs and neat installations.
  • LMR240 (used for 10m option): thicker dielectric, heavier braid and a more robust outer jacket for extended runs and outdoor durability.

Low-loss performance (approx. at 900 MHz):

  • LMR200 — 3 m (≈10ft): ~0.89 dB attenuation
  • LMR200 — 5 m (≈16ft): ~1.49 dB attenuation
  • LMR240 — 10 m (≈33ft): ~2.54 dB attenuation

Recommendation: Shorter cable lengths minimise signal loss — choose the shortest practical length for your installation. Use LMR200 for runs up to ~5 m; use LMR240 for longer runs (≈10 m) where durability and slightly higher shielding are required.

Product Images & Installation Guides

Egasky LPDA antenna front view Egasky LPDA antenna side view
Egasky LPDA antenna rear view Egasky LPDA antenna mounting detail

Directional antennas transmit signals farther in a fixed direction. Correct alignment during installation is very important.

Single point transmission (example): For boosting mobile signals, the antenna must be pointed toward the cell tower. See the illustrations below for guidance:

Find cell tower 1 Find cell tower 2
Find cell tower 3 Find cell tower 4
Find cell tower 5 Find cell tower 6

If you are unsure of the correct cell tower direction, tools such as OpenSignal, Cell Tower Locator or operator coverage maps can help identify the nearest tower.

Multipoint transmission (example): For Helium hotspots and similar multipoint use cases, consult the radiation pattern — horizontal beamwidth is approximately 90°. If your location resembles positions labeled B or C in Helium Explorer (i.e. nearby hotspots lie in one direction), pointing the antenna toward that cluster will increase witness opportunities.

Find witnesses 1 Find witnesses 2
Find witnesses 3 Find witnesses 4
Find witnesses 5 Find witnesses 6
Find witnesses 7 Find witnesses 8

Free technical support to help you find the best signal direction.

Outdoor Installation Notes:

Outdoor install 1 Outdoor install 2
Outdoor install 3 Outdoor install 4
Outdoor install 5 Outdoor install 6
  • Place the antenna as high as practical and aim it toward the desired signal source.
  • Ensure clear Line of Sight (LoS) where possible — avoid trees, large buildings and other obstructions.
  • Use appropriate waterproofing on connectors for outdoor exposure.
  • Tighten mounts and brackets securely to prevent movement in wind.
  • When using long cable runs, be aware of increased loss. Use LMR240 for durability on longer runs.

Line-of-Sight (LoS) Guidance

LoS 1 LoS 2
LoS 3 LoS 4
