AC input:  90-130V or 180V-260VAC, 47 to 63Hz

110V input , the out put current is half

Output power: 3KW
DC

output voltage: choose

Size:86*127*244mm
LED indicator light logo: red and green, double color instructions, red charging green finished or standby
Efficiency: >93%

Use for : lithium /lifepo4/LTO/lead acid battery

Charging Mode:6 Stages, CC, CV, Trickle

Output current :30A/25A/20A

Pretection:IP67 waterproof



Protect Characteristic
1.Short-circuit protection
2.Over-current protection
3.Over-voltage protection
4.Reverse Polarity Protection

5.Over-temperature protection


Work Conditions:
Ambient temperature: -5 - 40℃
RH: 5 - 95%
Max. altitude: 10000  meter
Cooling:
chargers use of forced air cooling system. Under dustless and
ventilated conditions, the full load temperature rise not exceeding 40℃.



Storage conditions

Ambient temperature: -40 - 70℃
RH: 0 - 95%

Max. altitude: 20000 meters.
