Average cutting efficiency: 60 kg/h
The diameter range of cut white lotus is: 14mm-21mm
No matter how big the lotus seeds are, they will not hurt the flesh. The machine is small in size, convenient in operation and low in price, suitable for home production. It completely solves the problems of difficult and slow shelling of lotus seeds, saving a lot of processing time for lotus farmers.
How to use the lotus cutting machine
1. Normal use:
Step 1: Fix the lotus root knife on the wooden bench, and put a bucket or empty carton at the lower discharge port.
Step 2: Put the fresh lotus seeds into the hopper.
Step 3: Turn the handle counterclockwise. At this time, the lotus seeds that have been cut into the shell will enter the barrel from the discharge port.
Second, the knife edge adjustment:
Step 1: Remove the four screws at the bottom of the lotus knife.
Step 2: Remove the knife holder inside the bottom.
Step 3: Use a Phillips screwdriver to disassemble the blade holder and adjust the blade height.
Step 4: Install the adjusted tool holder in sequence.
Notes on lotus seed chopper:
1. The chopped lotus seeds should not be soaked in water, otherwise it will slip in the machine and affect the cutting speed.
2. After using for a period of time, if there is dirt on the blade, it will affect the cutting effect. A knife needs to be extended from the blade window to remove dirt along the blade surface to avoid hurting people. blade.
3. Do not put double lotus seeds or other foreign objects into the machine, otherwise they will be stuck in the machine. When blocking is sent, blocking should be removed. If it is serious, it needs to be disassembled to remove. Do not shake the handle vigorously, otherwise the wheel will be damaged. The handle can withstand a maximum force of 200N (20kg force)
How to replace the blade:
After cutting 2000-3000kg shell lotus, or replace the blade according to the blade condition
Remove the base screws and separate the chopper from the base. You can see the correct knife and remove the blade to change the blade.
