980ZQ Nitrogen Air Gas Flushing Suction Continuous Band Sealer with Ink Coding
Video will open in a new window
Using the eBay App? Paste link into a browser window:
Description:
1. FRM-980ZQ series Nitrogen Flushing Packaging Machine can seal any heat-sealable materials.
2. Two Mode: Exhaust gas+Sealing;Gas Flushing+Sealing.
3. The print wheel equipped to the machine can be used for both R arrange and T arrange of types.
4. For types in R arrange, the machine can print two lines in font size two (18PT) or three lines in font size five (10.5PT). If necessary, counting device can be equipped as well.
Features:
1. Constant temperature control and temperature is adjustable.
2. Stepless speed regulation
3. Solid-ink coding is featured by high definition, various selectable colors, instant dry while printing, strong adhesive property.
Application:
FRM-980ZQ series Nitrogen Flushing Packaging Machine is applied to pack fragile or bulking objects generally.
Product Parameters:
|
Model |
FRM-980ZQ |
|
Voltage (V/Hz) |
AC 220/50 110/60 |
|
Moter Power (W) |
50 |
|
Suction Pump Power(W) |
750 |
|
Sealing Power (W) |
300*2 |
|
Printing Heating Power (W) |
40×2 |
|
Sealing Speed (m/min) |
0-12 (0-16) |
|
Sealing Width (mm) |
10 |
|
Temperature Range (℃) |
0-300 |
|
Printing Type |
Solid Ink Roller |
|
Distance from Sealing Center to Conveyor Table (mm) |
10-40 |
|
Distance from Base Plate to Interior Conveyor(mm) |
68-85 |
|
Conveyor Table Size (L×W) (mm) |
930×153 |
|
Overall Conveyor Loading (kg) |
≤10 |
|
External Dimensions (L×W×H) (mm) |
1050×550×900 |
|
Net Weight (kg) |
67 |
|
Gr. Wt. (kg) |
94 |
|
Net. Wt. (kg) |
80 |
|
Dimensions(cm) |
110*62*120 |
