What’s in the Box

Product Attributes

Outlet Outside Diameter: 0.31 in
Outlet Quantity: 1
Minimum Pressure: 116 PSI
Housing Width: 118 mm
Voltage: 12 VDC
Maximum Pressure: 123 PSI
Top Mount Diameter: 129.5 mm
Average Current Draw: 13 A
Housing Length: 150 mm
Width: 195 mm
Length: 215 mm
Height: 250 mm
Housing Width: 4.65 in
Minimum Flow Rating: 47.5 gph
Top Mount Diameter: 5.12 in
Housing Length: 5.91 in
Resistance Ohms Full: 50 Ohms
Average Flow Rating: 52 gph
Maximum Flow Rating: 55.5 gph
Minimum Free Flow Rate: 63.4 gph
Terminal Quantity: 7
Width: 7.68 in
Outlet Outside Diameter: 7.89 mm
Length: 8.46 in
Height: 9.84 in
Resistance Ohms Empty: 990 Ohms
Pump Type: Electric
Connector Gender: Female
Fuel Type: Gas
Pump Design: Impeller
In Tank or External: In Tank
Internal Or External Strainer: Internal
Terminal Gender: Male
Mounting Hardware Included: No
Lock Ring Included: No
Gasket Or Seal Included: No
Wire Harness Included: No
Terminal Type: Pin
Housing Material: POM Plastic
Outlet Type: Quick Connect
Connector Shape: Race Track
Universal Or Specific Fit: Specific
Grade Type: Standard Replacement
Connector Color: White
Fuel Filter Included: Yes
Fuel Sending Unit Included: Yes
Fuel Tank Pressure Sensor Included: Yes
Regulator Included: Yes
Strainer Included: Yes
Negative Ground: Yes
