Features：

ISO / IATF 16949 certification, direct installation, made of high-quality materials, in line with OEM specifications

The highest grade plastic tank with aluminum core-can withstand rust and abrasion

Reliable and durable, quality checked, 100% leak tested

lifetime warranty

30-day free return period

All products are quality checked and 100% leak tested

Plug-in type-direct installation, easy to install

Original specifications​

Part Number：

 164000H030, 164000H200, 1640028280, 16410YZZAF, 2210505,

2436, 2437, 432307, 8012437, 8200, 9659, CSF3143, CU2436,

CU2437, Q2437, RAD2437, SBR2437, TO3010256, TY37063A

Fitment:

Year Make Model Engine
2002 For TOYOTA Camry 2.4l L4
2003 For TOYOTA Camry 2.4l L4
2004 For TOYOTA Camry 2.4l L4
2004 For TOYOTA Solara 2.4l L4
2005 For TOYOTA Camry 2.4l L4
2005 For TOYOTA Solara 2.4l L4
2006 For TOYOTA Camry 2.4l L4
2006 For TOYOTA Solara 2.4l L4
2007 For TOYOTA Solara 2.4l L4
2008 For TOYOTA Solara 2.4l L4

Package Including:

As the picture shows

Notice:

The optimal concentration of LLC (Long Life Coolant) is determined according to the specific ambient temperature of each region. In addition, LLC (Long Life Coolant) must be replaced regularly.

Use and maintenance:

1. The radiator should not be in contact with any acid, alkali or other corrosive properties.
2. It is recommended to use soft water. Hard water should be used after softening treatment to avoid blockage of the radiator and the generation of scale.
3. Use antifreeze, in order to avoid corrosion of the radiator, be sure to use a long-term anti-rust and antifreeze that is produced by a regular manufacturer and meets national standards.
4. In the process of installing the radiator, please do not damage the radiator (sheet) or bump the radiator to ensure the heat dissipation capacity and sealing.
5. When the radiator is completely drained and then filled with water, turn on the drain switch of the engine block first, and then close it when water flows out to avoid blisters.
6. In daily use, check the water level at any time, and add water after stopping the machine to cool down. When adding water, slowly open the water tank cover, and the operator should stay away from the water filling port as much as possible to prevent burns caused by high-pressure steam spraying from the water filling port.
7. In winter, in order to prevent the core from rupturing due to freezing, such as long-term parking or indirect parking, the water tank cover and drain switch should be released to release all the water.
8. The effective environment of the spare radiator should be kept ventilated and dry.
9. Depending on the actual situation, the user should completely clean the core of the radiator within 1 to 3 months. When cleaning, rinse with clean water along the reverse side of the air inlet.
10. The water level gauge should be cleaned once every 3 months or depending on the actual situation, all parts are removed and cleaned with warm water and non-corrosive detergent.
