ITC-306T : Temp. Controller With Probe sensor, Day and night Timer Only For Heating Device,using For Pet, Reptiles , turtles , Aquarium, Fishing Keeping etc
Main features:
1. ITC-306T is a pre-wired heating output temperature controller(No Cooling Controller) with time function specifically for breeding and planting.
2. It can be set to two different temperatures with its function of dual time cycle setting during 24 hours according to the day and night, which can more suitable for the physiological needs of animals and plants.
3. It can be widely use in over-heat protection and automatic temperature control system of all sorts of electrical equipment for aquarium, pets breeding, hatching, fungus fermenting, and seed germination accelerating, etc.
4. This plug and play product is designed with dual LCD display,
5. It offers the optional display of Centigrade or Fahrenheit, which makes it more humanized temperature control.
6. With large power output 2400W, it's suitable for most applications.
7. The temperature can be controlled more accurately with its function of temperature calibration and temperature hysteresis.
Specification:
- Temperature Control Range: -50~99 °C / -58~210 ° F
- Temperature Resolution: 0.1 ° C / 0.1° F
- Temperature Accuracy:±1°C (-50~70°C) / ±2°F (-58~160°F)
- Input Power : 100 ~240VAC, 50Hz/60Hz
- Temperature Control Output: Max. 10A, 100V ~240V AC
- Sensor Type: NTC sensor (Including)
- Sensor Length: 2m / 6.56ft
- Relay Contact Capacity: Heating (10A, 100-240VAC)
- Input Power Cable Length: 1.5m (5ft)
- Output Power Cable Length: 25cm (1ft)
- Dimension: Body:140x68x33mm (5.5x2.7x1.3 inch.)
- Socket:85x42x24mm (3.3x1.7x1 inch.)
- Ambient Temperature : -30~ 75 ° C / -22~ 167 ° F
- Storage: Temperature -20~ 60 ° C / -4~ 140 ° F
- Humidity 20~85% (No Condensate)
- Warranty: 1 Year
Important note:
- Control two heaters at same temperature at the same time.
- If you want to control 20~25°C, please set TS=25, DS=5. Only current temperature lower than 20°C,heating lamp on and start heating.
- If between 20~25°C, heating lamp off,no heating output.
- The probe is waterproof, but if want to immerse it under water for a long time, please use waterproof tape to bind probe & wire connection for double protection
- Please note the display will not dim
Note: Heating Only
ITC-306T-WIFI : Inkbird 2.4G WiFi Remote Control Thermomstats Only Heating Temperature Controller, 24 Hours Digital Cycle Timer Thermostat for Greenhouse, Germination, Reptiles, Incubation, Heating Only, iOS & Android
Features:
【WiFi Remote Control】: It also supports 2.4G Wi-Fi connection, you can monitor and control the device with your phone from everywhere.
【APP Control】: Supports temperature graphs, alarms, ℃/℉ switch and timer setting. All parameters and functions can be set through the app.
【Dual Relay】: One relay for control and one relay for protection, 100~240Vac 50/60Hz 10A MAX.
【Double Sockets】: supports 2 heaters at a time. The controller dose not support cooling mode, only heating.
【C/F Reading】: Display unit supports Celsius°C or Fahrenheit℉
【Dual Display】: Displays the current measured temperature and the target temperature at the same time.
【Plug-n-Play】: easy to operate. Just plug in the device and set it according to your needs, no more tedious installation is needed.
【Cycle Timers】: 2 timers are available on the controller, you can set different target values at different period of time according to your needs and let the timers work in a loop.
Specification:
-Brand: INKBIRD
-Model: ITC-306T-WIFI
-Power: 100~240Vac 50/60Hz 10A MAX
-Temperature control range: -50.0℃~99.0℃/-58.0℉~210℉
-Temperature measurement range: -40.0℃~120℃/-40.0℉~248℉
-Temperature display accuracy: 0.1℃/℉(<100℃/℉),1℃/℉(>=100℃/℉)
-Display unit: Celsius°C or Fahrenheit℉
-Ambient temperature: -20°C~40°C/-4.0℉~104℉
-Storage environment: Temperature: 0°C~60°C/32℉~140℉; Humidity: 20~80%RH (unfrozen or condensation state)
