36-port 10G Managed L2+ Core PoE Switch 10/100/1000M PoE RJ45 portsGigabit SFP

36-port 10G L2+ Managed Core PoE Switch, 24*10/100/1000M PoE RJ45 ports + 8*Gigabit SFP ports + 4*10G SFP+ ports, compatible with both IEEE 802.3af/at standard. Max PoE port power: 30W, can be set by management system. Total input power is 400W.

Technical parameter list
Product Name	36-port 10G Managed L2+ Core PoE Switch
Model	ONV-POE36036PFM
Connector Type	2410/100/1000M PoE RJ45 ports + 8Gigabit SFP ports + 4*10G SFP+ ports
Network Media	10BASE-T: UTP Cat 3, 4, 5 (≤100 Meters) 100BASE-TX: UTP Cat 5 or more (≤100 Meters) 1000BASE-T: UTP Cat 5 or more (≤100 Meters)
Bandwidth	598G
Address Database Size	32K
MTBF	100,000 hours
Forwarding Mode	Store and Forward
Buffer Memory	32M
Network Protocols	IEEE 802.3,10BASE-T Ethernet; IEEE 802.3u, fast Ethernet Standard; IEEE 802.3ab, gigabit Ethernet Standard; IEEE 802.3z, gigabit Ethernet Fiber Standard;(AOC fiber cable) IEEE 802.3ae,10G Ethernet Standard; IEEE 802.3x, full-duplex Ethernet data link layer flow control;
PoE Ports	24*PoE Ports
PoE Port Power	Max 30W
PoE Standard	IEEE802.3af/at
Working Environment	-40~+80°C
Certification	CE, , RoHS
Transmission Distance	100 meters for RJ45 port
Power Supply Type	end-span(1/2+, 3/6-)
QoS	Yes
VLAN	Yes
Product Size	44029044.5mm
Warranty	1 year

High-performance of both hardware and software

This 10G L2+ Core PoE Switch uses top-rated 10G network switching chip, multiple layers PCB design, as well as self-developed switch software system. With combination of hardware and software, it improves product quality from forwarding stability, packet processing speed, and other work capability.

Support the fast ring network protocol, free configuration

The switch supports stable and reliable fast Ring Protection Protocol(RSTP). It Achieved real ring loop redundancy protection. Besides, there is no need to configure 10G port when users using this switch, to reduce probability of network failure.

Strong network security

Support dynamic or static binding by users’ definition, such as IP, MAC, VLAN, PORT, etc. Support port isolation, to prevent communication between two neighbor network equipment within the same broadcast domain , for reducing network risk; Supports perfect storm control function which can suppress broadcast, multi-cast, and uni-cast storm; Support specific ARP inspection which can effectively prevent ‘‘ARP spoofing attack’’ created by hackers or attackers via ARP packets.

Convenient management and maintenance
By easy WEB interface(http and https protocol supported), you can conveniently operate and configure all kinds of function in this switch. Support management by CLI, Telnet, Console port, which is more suitable for professional network administrator; It also allow reset by one-press, making maintenance easier.

Feature

◆24*10/100/1000M PoE RJ45 ports + 8*Gigabit SFP ports + 4*10G SFP+ ports

◆Support L2+ Switching features, including VLAN, TRUNK, Mirroring, Port isolation/flow control/speed limit, Storm control, QOS, ACLs etc.

◆Support spanning tree STP, RSTP.

◆Jumbo frames support up to 9.6K kilobytes

◆Support enhanced management through WEB, CLI, TELNET, SNMP

◆Support cable diagnosis

◆24 ports support PoE. Compatible with both IEEE 802.3af/at. Allow PoE configuration for each PoE port

Target Industries
◆HD monitor transmission and power supply
◆Wireless AP layout transmission and power supply
◆Network telephone transmission , intelligent house and home system
◆Intelligent transportation supervisory system(ITS)
◆ High-speed Way supervisory/Tele-Communication System
◆ Security protection system, TV medical treatment
◆ Long-distance Muti-media Schooling, Campus monitoring
◆ Long-distance broadcast television transmission system
◆ High-building Security Protection, Military Tele-Com projects

Ordering Information

Product Model: ONV-POE36036PFM
Product Description: 36-port 10G L2+ Managed Core PoE Switch, 24*10/100/1000M PoE RJ45 ports + 8*Gigabit SFP ports + 4*10G SFP+ ports, compatible with both IEEE 802.3af/at standard. Max PoE port power: 30W, can be set by management system. Total input power is 400W.
Note: Default power supply pin type is end-span(1/2+, 3/6-)
