Compatible With:

Mitsubishi Lift Truck
FD-10 S4E 1981-1983
FD-14 S4E 1981-1983
FD-15 S4E 1981-1983
FD-15T 4DQ50W 1980-1999
FD-20 S4E / S4S 1983-1992
FD-20B-D S4E / S4S 1983-1989
FD-20B-DS S4E / S4S 1983-1989
FD-20D S4E / S4S 1983-1989
FD-23 S4E Diesel 1983-1992
FD-25 S4E / S4S 1983-1999
FD-25B-D S4E / S4S 1983-1989
FD-25B-DS S4E / S4S 1983-1989
FD-25D S4E / S4S 1980-2001
FD-25DS S4E / S4S 1980-1999
FD-25T S4E / S4S 1980-2001
FD-28 S4E Diesel 1981-1992
FD-30 S4E / S4S 1980-1999
FD-30B-D S4E / S4S 1980-1999
FD-30B-DS S4E / S4S 1980-1999
FD-30D S4E / S4S 1980-1999
FD-30DS S4E / S4S 1980-1999
FD-30T S4E / S4S 1980-2001
FD-35A S4E / S4S 1981-1983
FD-35A-D S4E / S4S 1981-1983
FD-35AB-D S4E / S4S 1981-1983
FD-35AT S4E / S4S 1981-1983
FDC-20-D S4E / S4S 1981-1983
FDC-25-D S4E / S4S 1981-1983

Isuzu Engines - Industrial
Misc. Industrial Equipment 4JB1 Engine 1988-2007

TCM Equipment Lift Truck
FD20Z Isuzu C240 Diesel 1983-2004
FD23Z Isuzu C240 Diesel 1983-2004
FD25Z Isuzu C240 Diesel 1983-2004
FD28Z Isuzu C240 Diesel 1983-2004
FD30Z Isuzu C240 Diesel 1983-2004

TCM Equipment Misc. Equipment
SD10Z Isuzu C240 Diesel 1983-2004
SD12Z Isuzu C240 Diesel 1983-2004

Specifications:

Volt: 24
Amps: 20
Regulator Clock: 2:00
Mount Hole ID 1: M8x1.25 Threaded
Mount Hole 2 Type: Unthreaded
Mount Hole ID 3: 8mm Unthreaded
Fan Location: External
Regulator Location: Internal
Terminal ID 2: B+ M5x0.8
Polarity: Negative
Number of Grooves: 1
Pulley Type: Solid
Pulley Outer Diameter: 2.835"/72mm
Note: 80mm Between Bottom Mounting Ears @ 2-Blade Plug @ Belt Width 11mm

Replaces OEM Part Numbers:

Denso: 210-9002, 211-9002
Hitachi: LR220-23, LR220-24
Isuzu: 5812003300, 5812003350
Lester: 12114, 12322
