N42 Neodymium Disc Magnets — 5 x 2 mm

Nickel-Copper-Nickel coated • Axially magnetised • Packs of 1, 10, 25, 50 and 100

The basing magnet. 470 g of pull from a 2.2 mm recess — enough to hold a painted miniature in a steel-lined case through a car journey, without needing a deep hole.

Why this size

✓ Built for magnetised bases and transport trays. This is the size most people are actually looking for when they want miniatures to stay put in a steel-lined case.

✓ Calculated pull: 470 g at direct contact. Zero gap, clean flat steel. Magnet-to-magnet also 470 g. Reference value, not a guaranteed working load.

✓ More pull than a 4 x 3 mm disc, a millimetre less depth. 470 g against 450 g, from 2.2 mm instead of 3.2 mm. If you can drill 5 mm wide, this is the better magnet.

✓ Wide enough to sit stable. A 5 mm face resists rocking, so a based miniature sits flat on the tray instead of tipping on one edge.

✓ Honest N42 grade. We state the grade we actually buy. If you see the same disc advertised as N52 at this size, treat the claim with caution.

What it is

A sintered neodymium (NdFeB) disc, 5 mm across and 2 mm thick, magnetised through its thickness — the poles are the two flat faces, not the curved edge. Fitted into the underside of a base it grips a steel sheet across its whole face, which is what keeps a model upright rather than merely attached.

470 g is the point where transport stops being a worry. A 28mm infantry model on a steel-lined tray will not shift on a motorway, and a larger model on a 40 mm or 50 mm base can be carried with two of these spaced apart. It is also enough for heavier jobs away from basing — cast metal parts, removable terrain sections, display plinths.

One caution up front, because it matters more at this strength than at any smaller size: a magnet this strong can be stronger than the glue joints on the model itself. See the basing section below.

Specifications

Diameter	5 mm
Thickness	2 mm
Weight per magnet	0.30 g
Material	Sintered neodymium iron boron (NdFeB)
Grade	N42
Coating	Nickel-Copper-Nickel (NiCuNi), triple layer
Magnetisation	Axial — poles on the flat faces
Pull to steel (calculated)	470 g / 4.61 N at direct contact, zero gap
Magnet-to-magnet pull	470 g, bare faces in direct contact
Shear (sideways) estimate	Approximately 70 g — sideways load is far weaker than direct pull
Drill bit size	5 mm
3D print hole size	5.1 mm
Maximum working temperature	Approximately 80°C — standard for N42
Country of manufacture	China

Pull figures are calculated reference values for a clean, flat, direct steel contact with no air gap. Paint, primer, glue layers, curved surfaces and any gap at all will reduce holding force, in some cases substantially. Treat these numbers as a way to compare sizes to each other, not as a guaranteed working load.

What you get

▪ The pack size you select from the dropdown: 1, 10, 25, 50 or 100 magnets

▪ Supplied stacked pole-to-pole in a resealable bag

▪ Every magnet is the same 5 x 2 mm N42 disc — the only difference between variants is the count

Basing miniatures with this size

The usual arrangement is a magnet recessed into the underside of the base, meeting a steel sheet lining the transport tray or case. Magnet against steel is easier to live with than magnet against magnet: there is no polarity to get wrong, models can be placed in any orientation, and the hold is still firm.

▪ Small bases: one magnet, centred, is normally plenty for a standard infantry model.

▪ Larger bases: two magnets spaced well apart do a better job than one strong one in the middle. Spacing is what stops a model rocking; raw pull is not.

▪ Top-heavy models: spacing matters even more. A tall model on a single central magnet can pivot on it.

▪ Check base thickness first. A 2.2 mm recess needs a base that can take it. Thinner bases, or ones you do not want to weaken, are better served by our 5 x 1 mm disc.

The honest warning about strong basing magnets

At 470 g the magnet can easily be stronger than the glue holding your model together. Lifting a miniature straight up out of a steel-lined tray puts that entire force through the model — and the weakest joint gives first. Slender ankles, glued-on cloaks, banner poles and separately attached weapons are the usual casualties. Lift by sliding the model sideways off the steel first, then up. Sideways takes around 70 g instead of 470 g. If you regularly transport delicate models, a smaller magnet is genuinely the better choice, not a compromise.

What this size is for

Well suited to: magnetised miniature bases and steel-lined transport trays • movement trays and regiment bases • cast metal weapon arms and turrets • removable terrain and diorama sections • display plinths and cabinet mounts • heavier craft closures.

Choose 5 x 1 mm instead when: the base or panel is too thin for a 2.2 mm recess, or you are transporting delicate models and would rather have a gentler hold.

Look at 6 mm for: large bases, heavy display pieces and anything where two 5 mm magnets still are not settling it.

Working with them

Fit the magnet flush or slightly recessed, never proud. A magnet standing even a fraction above the underside of the base makes the model rock, and the rocking is far more annoying than the extra grip is useful. Sink it until it sits level with the surrounding plastic.

The glue joint is the weak point, not the magnet. 470 g will pull a badly seated magnet out of its recess rather than release from the steel. Drill a snug 5 mm hole, wick thin CA down the side walls, and let it cure fully before testing.

Mark the stack before you separate it. Put a dot of permanent marker on one face of the whole stack while it is still assembled. Every magnet then carries the same reference face — essential if you are pairing magnets rather than using steel sheet.

Slide, do not pull. Separating a stack by pulling straight apart takes the full 470 g. Sliding one magnet sideways off takes roughly a seventh of that, and the same trick is how you lift models out of a tray without stressing them.

Keep paint out of the joint. Basecoating the underside of a base with the magnet already fitted adds a layer between magnet and steel. Mask the face, or fit the magnet after painting.

Honest limitations

▪ Strong enough to damage the model. The most common problem with this size is not weak hold, it is a delicate part failing before the magnet does. Read the basing warning above before you commit a whole army to it.

▪ It needs 5 mm of width and 2.2 mm of depth. Many standard bases are only 2 to 3 mm thick. Measure before you drill.

▪ Sideways load is much weaker than straight pull. Around 70 g. That is a feature when lifting models out of a tray, and a limitation if the load on your joint is a sliding one.

▪ Steel quality changes the result. Thin steel paper holds noticeably less than a proper steel sheet, because there is less material for the field to work into. The 470 g figure assumes clean, flat, reasonably thick steel.

▪ Neodymium is brittle. These are sintered, ceramic-like magnets. At 470 g they snap together hard enough to chip, crack or nip a fingertip if you let them jump across a gap.

▪ Indoor use. NiCuNi plating resists handling and normal indoor humidity, but it is not a marine or outdoor coating.

▪ Heat weakens them permanently. Above roughly 80°C an N42 magnet loses strength and does not recover on cooling. Keep them away from ovens, curing lamps and hot cars.

Important safety information

Warning — strong magnets. For adult hobby and technical use. Not a toy.

Swallowing two or more magnets can cause serious internal injury. Magnets can attract to each other through the wall of the intestine, causing blockage or perforation. Seek immediate medical attention if a magnet is swallowed or inhaled. Keep away from children and pets at all times.

Keep magnets away from pacemakers, implanted defibrillators and hearing aids. Keep them away from bank cards, hard drives and other magnetic media.

Handle with care — neodymium is brittle and can chip. Store magnets in their bag, away from loose steel and craft blades.
