DT-156 Dual Technology Features Automatic Selection of Magnetic Induction or Eddy Current Measurement Techniques
Non-magnetic coatings (e.g. paint, zinc) on steel
Insulating coatings (e.g. paint) on no-ferrous metals
No-ferrous metals coatings on insulating substrates
Menu operation system
Two working modes: DIRECT and GROUP mode
One point calibration, two points calibration and basic calibration easily
Delete single readings and all group readings easily
Low battery, error indication



Features	DT-156
Non-magnetic coatings (e.g. paint, zinc) on steel	*
Insulating coatings (e.g. paint) on no-ferrous metals	*
No-ferrous metals coatings on insulating substrates	*
Menu operation system	*
Two measuring modes: CONTINUE and SINGLE mode	*
Two working modes: DIRECT and GROUP mode	*
Statistic Display: AVG, MAX, MIN, NO., S.DEV	*
One point calibration, two points calibration and basic calibration easily	*
Memory for 400 readings (80 DIRECT and 320 GROUP readings)	*
Delete single readings and all group readings easily	*
High alarm and Low alarm for all working modes	*
Low battery, error indication	*
USB interface for PC software	*



Size (H x W x D): 113.5mm x 54mm x 27mm
Weight: 110g



Specifications	DT-156
Sensor probe	F	N
Working principle	magnetic induction	Eddy current principle
Measuring range	0~1250um	0~1250um
Guaranteed tolerance (of reading)	(+/- 3%+1)um	(+/- 3%+1.5)um
Repeatability	(+/- 1%+1)um	(+/- 1%+1)um
Low range Precision	0.1um	0.1um
Minimum curvature radius	1.5mm	3mm
Diameter of Minimum area	7mm	5mm
Basic critical thickness	0.5mm	0.3mm
